CUBETAPE PRO Quick Start Manual

Cubetape PRO Quickstart Guide

Exterior Overview

Press to record measure
Scan barcode

Power On/Off

To turn on the device, once press
To shut down the device, press
"power off" is indicated on screen (or 5 beeps are heard).

Insert Pallet

While the cursor is in the length field, press

Return to Last Recorded Data

Press several times until the cursor is in the length field;
Press will display the last recorded measurement on screen.

Append

The append function enables the operator to sum three measurements of length together, especially
when the item length is longer than the 3 meter tape.
After measuring length 1, press
Measure length 2 and length 3;
Record appended measurement by pressing
The length recorded will be the sum of length 1, 2 and length 3.
www.cubetape.com
USB Portal Charge Light
LED
Send data record
Append; save data
.
for approximately 3 seconds, then release when
or to insert the default pallet length and width.
to append;
or
Tape Tip
Tape Tip
Rubber Boot Protective
Backspace; power on/off
All buttons can be used for navigation
under menu mode except for
;
Battery Compartment
Tape Cassette
.
