CUBETAPE C190SHP Quick Start Manual

Quick Start Guide for C190SHP,
C190POS, C190DSK – Page 1
Contents of C190SHP:
Cubetape
C190 POS
Installation:
Bluetooth Pairing:
• After cradle installation, power on Cubetape
(hold the "m" button down for 2 seconds).
• Scan the Bluetooth pairing barcode on the front of the cradle.
• Cubetape is successfully connected to the cradle, when the Blue LED
indicators on Cubetape and the cradle are permanently ON.
• If the Blue LED indicators continue to flash,
re-scan the Bluetooth pairing barcode on the cradle.
Operations and Measuring:
Extend the tape, press the
'm' button
to scan the barcode
measurement on the tape
• Blue LED indicators are on permanently when connected
• To scan a barcode ID, press 'm'
• Blue LED ON when connected to host
C190DSK
Cradle
PC
USB
Cable
to pair Cubetape with its cradle
Quickstart
Guide
DIP switches beneath cradle:
Cradle
CORRECT
C190CRC
USB Cable
OFF ON
BT MODE
MASTER SLAVE
COMMS MODE
USB-VPC USB-HID
RESERVED
--
RESERVED --
Pairing
barcode
√
www.cubetape.com
DEFAULT
ON
ON
-- OFF
-- OFF
INCORRECT
x
