How to Use
• When the stabilizer is powered on, rotate the roll axis or pan axis manually until
the axis triggers the built-in lock device, then the stabilizer will enter standby mode
automatically. Unlock the roll axis and pan axis to wake up the stabilizer. Before
restarting the stabilizer, make sure the roll axis and pan axis are unlocked.
• The picture below demonstrates the roll axis is rotated to locking status.
Under Locking Mode, the rotation angle of the pan axis can be adjusted manually by
moving the pan axis to certain angle and hold for 2 seconds(please do not exceed
the limit) to fix it in the angle.

Standby Mode

Manual Reposition
