- Page 1 Assembly Instructions Model No. 1700040003 4PC Deep Seating Set - Loveseat Questions, problems, or missing parts? Before returning to the store, call Customer Service. 1-866-988-3300 8 a.m. - 5 p.m., PST Monday - Friday Retain this manual for future use.
-
Page 2: Table Of Contents
Contents Safety Instructions Parts List Assembly Cleaning & Maintenance Warranty IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY. 1700040003... -
Page 3: Safety Instructions
Do not place heavy objects on the chair. WARNING When not in use, secure the product in a cool and covered location. WARNING Do not locate the product near any heat source. WARNING Warning: Weight limit for the chairs is 250lbs (113.39Kg) for each set. 1700040003... -
Page 4: Parts List
Left Arm - 1 M6x15 Bolt - 6 Right Arm - 1 M6x28 Bolt - 6 Seat Frame - 1 M6 Flat Washer - 12 Back Frame - 1 Seat Cushion - 2 Back Cushion - 2 Pillow - 2 1700040003... -
Page 5: Assembly
Attach the back frame (J) to the left arm (G) using M6X18 bolts (AA) and M6 washers (DD) as shown below. Attach the seat frame (I) to the left arm (G) using M6X28 bolts (BB) and M6 washers (DD) as shown below. NOTE: Loosely tighten all the bolts using the hex wrench (GG). 1700040003... - Page 6 M6 washers (DD) as shown below. Attach the seat frame (I) to the right arm (H) using M6X28 bolts (BB) and M6 washers (DD) as shown below. NOTE: Loosely tighten all the bolts using the hex wrench (GG). 1700040003...
- Page 7 Requires: E, F Once all the bolts are in place, fully tighten all the bolts. Ensure that all connections are secure before use. Place the seat cushions (E), back cushions (F) and pillows (N) to finish the assembly of the chairs. 1700040003...
-
Page 8: Cleaning & Maintenance
• Store furniture in an upright position to prevent water building up in frames, as this will cause corrosion and freeze damage in cold climates. • Consider covering your furniture when not in use for long periods of time (and during bouts of inclement weather). 1700040003... -
Page 9: Warranty
After cleaning cushions tip on end and allow to drip dry. (Never use a commercial or home dryer to tumble dry fabric goods). Do not use bleach or solvents to clean any product! This will void the warranty. 1700040003... - Page 10 TO BE DEFECTIVE UNDER THE TERMS AND CONDITIONS AS STATED IN THIS WARRANTY. NEITHER ARISING OUT OF ANY BREACH OF THIS WARRANTY OR NEGLIGENCE EVEN IF IT HAS BEEN ADVISED ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OTHER THAN THE WARRANTY DESCRIBED OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY DISCLAIMED. 1700040003...
- Page 11 Assembly Instructions Model No. 1700040003 4pc Deep Seating Set - Coffee Table Questions, problems, or missing parts? Before returning to the store, call Customer Service. 1-866-988-3300 8 a.m. - 5 p.m., PST Monday - Friday Retain this manual for future use.
- Page 12 Contents Safety Instructions Parts List Assembly Cleaning & Maintenance Warranty IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY. 1700040003...
-
Page 13: Safety Instructions
WARNING Do not place heavy objects on the table. WARNING When not in use, secure the product in a cool and covered location. WARNING Do not locate the product near any heat source. 1700040003... -
Page 14: Parts List
Parts List Table Top - 1 M8x50 Bolt - 8 Table Leg - 4 M8 Flat Washer - 8 M8 Spring Washer - 8 Wrench - 1 1700040003... -
Page 15: Assembly
Place the table top (L) upside down on a soft surface. Attach the table legs (M) to the table top (L) using M8x50 hex bolts (CC), M8 spring washers (FF), and M8 washers (EE). NOTE: Loosely tighten all the bolts using the wrench (HH). 1700040003... - Page 16 Assembly STEP 2 Once all the bolts are in place, fully tighten all the bolts. Turn the table right side up. Ensure that all connections are secure before use. 1700040003...
-
Page 17: Cleaning & Maintenance
• Store furniture in an upright position to prevent water building up in frames, as this will cause corrosion and freeze damage in cold climates. • Consider covering your furniture when not in use for long periods of time (and during bouts of inclement weather). 1700040003... -
Page 18: Warranty
After cleaning cushions tip on end and allow to drip dry. (Never use a commercial or home dryer to tumble dry fabric goods). Do not use bleach or solvents to clean any product! This will void the warranty. 1700040003... - Page 19 TO BE DEFECTIVE UNDER THE TERMS AND CONDITIONS AS STATED IN THIS WARRANTY. NEITHER ARISING OUT OF ANY BREACH OF THIS WARRANTY OR NEGLIGENCE EVEN IF IT HAS BEEN ADVISED ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OTHER THAN THE WARRANTY DESCRIBED OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY DISCLAIMED. 1700040003...
- Page 20 Assembly Instructions Model No. 1700040003 4PC Deep Seating Set - Lounge Chairs Questions, problems, or missing parts? Before returning to the store, call Customer Service. 1-866-988-3300 8 a.m. - 5 p.m., PST Monday - Friday Retain this manual for future use.
- Page 21 Contents Safety Instructions Parts List Assembly Cleaning & Maintenance Warranty IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY. 1700040003...
-
Page 22: Safety Instructions
Do not place heavy objects on the chair. WARNING When not in use, secure the product in a cool and covered location. WARNING Do not locate the product near any heat source. WARNING Warning: Weight limit for the chairs is 250lbs (113.39Kg) for each set. 1700040003... -
Page 23: Parts List
Left Arm - 2 M6x15 Bolt - 12 Right Arm - 2 M6x28 Bolt - 12 Seat Frame - 2 M6 Washer - 24 Back Frame - 2 Hex Wrench - 1 Seat Cushion - 2 Back Cushion - 2 1700040003... -
Page 24: Assembly
Attach the Back Frame (D) to the left arm (A) using M6X18 bolts (AA) and M6 washers (DD) as shown below. Attach the seat frame(C) to the left arm (A) using M6X28 bolts (BB) and M6 washers (DD) as shown below. NOTE: Loosely tighten all the bolts using the hex wrench (GG). 1700040003... - Page 25 M6 washers (DD) as shown below. Attach the seat frame (C) to the right arm (B) using M6X28 bolts (BB) and M6 washers (DD) as shown below. NOTE: Loosely tighten all the bolts using the hex wrench (GG). 1700040003...
- Page 26 Once all the bolts are in place, fully tighten all the bolts. Turn the chair right side up. Ensure that all connections are secure before use. Place the seat cushions(E) and back cushions (F) to finish the assembly of the chairs. 1700040003...
-
Page 27: Cleaning & Maintenance
• Store furniture in an upright position to prevent water building up in frames, as this will cause corrosion and freeze damage in cold climates. • Consider covering your furniture when not in use for long periods of time (and during bouts of inclement weather). 1700040003... -
Page 28: Warranty
After cleaning cushions tip on end and allow to drip dry. (Never use a commercial or home dryer to tumble dry fabric goods). Do not use bleach or solvents to clean any product! This will void the warranty. 1700040003... - Page 29 TO BE DEFECTIVE UNDER THE TERMS AND CONDITIONS AS STATED IN THIS WARRANTY. NEITHER ARISING OUT OF ANY BREACH OF THIS WARRANTY OR NEGLIGENCE EVEN IF IT HAS BEEN ADVISED ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OTHER THAN THE WARRANTY DESCRIBED OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY DISCLAIMED. 1700040003...
