Summary of Contents for Royal garden BLADCH609
- Page 2 Contents Safety Instructions Parts List Assembly Cleaning & Maintenance Warranty IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY. BLADCH609...
-
Page 3: Safety Instructions
Do not place heavy objects on the chairs. WARNING When not in use, secure the product in a cool and covered location. WARNING Do not locate the product near any heat source. WARNING Warning: Weight limit for the chairs is 250lbs (113.39Kg) for each set. BLADCH609... - Page 4 Chair Parts List Chair back frame - 1 M8x45 bolt - 4 Chair base - 1 Rocker place - 4 Chair assembly - 1 Lock washer - 4 M8 bolt - 4 Seat cushion - 1 Wrench - 2 BLADCH609...
-
Page 5: Chair Assembly
Chair Assembly STEP 1 Note: The Chair Assembly (C) can only be installed in one direction. Please note the correct direction. STEP 2 Requires: AA, BB, CC, DD, EE, A, C BLADCH609... - Page 6 Assembly Chair Assembly STEP 3 Requires: A, B STEP 4 BLADCH609...
- Page 7 This will help prevent mildew by removing dirt particles that may accumulate. • Do not clean with abrasive materials, bleach, or solvents. • Store the chairs in a dry, sheltered place when not in use. weather such as rain, hail, sleet, snow, or wind. BLADCH609...
- Page 8 Assembly Instructions Model No. BLARTT109 Dining Table Questions, problems, or missing parts? Before returning to the store, call Customer Service. 1-866-988-3300 8 a.m. - 5 p.m., PST Monday - Friday Retain this manual for future use.
- Page 9 Contents Safety Instructions Parts List Assembly Cleaning & Maintenance Warranty IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY. BLARTT109...
- Page 10 Safety Instructions WARNING Please keep children out of the assembly area before assembly. WARNING Never use this product as support. Do not shake, lean, or climb on the product at any time. WARNING Do not place heavy objects on the table. WARNING When not in use, secure the product in a cool and covered location.
- Page 11 Table Parts List Table top - 1 M6x20 bolt and washer - 8 Table leg - 4 M6x28 bolt and washer - 8 Table frame - 1 Hex wrench - 1 Umbrella Ring - 1 Decorative Umbrella Hole Cap - 1 BLARTT109...
- Page 12 Table Assembly STEP 1 Requires: AA, CC, A, B Attach the Table Leg (B) to the Tabletop (A), using a M6x20 Bolt with Washer (AA). Hand tighten only. Repeat for all four Table Legs. STEP 2 Requires: BB, CC, C Connect the Table Frame (C) to the Table Legs (B) using M6x28 Bolts with Washers (BB).
- Page 13 Table Assembly Assembly STEP 3 Requires: D, E Cleaning & Maintenance • For best results, clean the frame with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. • Do not clean with abrasive materials, bleach, or solvents. •...
