ASSEMBLY INSTRUCTIONS

Accessory Pack Contents

• LEG BOLT (⅜-16 x 6" Carriage Bolt)
• NUT (⅜-16 Hex Nut)
• WASHER (½" ID Fender Washer)
(additional leg bolts, nuts and washers secure the legs to the table for shipment and are not part of the hardware pack)
• SMALL PUCK – Fluorescent
• SMALL PUCK – Soft White
• SCORE POST ASSEMBLY
• #8 x 1½ " FLAT HD PH BLACK SCREWS
• #8 x ⅝ BLACK TRUSS HEAD SCREWS
• SANDPAPER
• LEG BOOT
• LEG SHIMS
• MALLET

Tools Required

• PHILLIPS SCREWDRIVER
• 9/16" BOX-END OR SOCKET WRENCH
• ALL-PURPOSE CLEANER
• RUBBING ALCOHOL
• CLEAN CLOTH
(Fantastik, Formula 409, Windex or equivalent)
Order replacement parts at www.valleydynamoparts.com
© 2020 Valley-Dynamo
part # ni870010421
part # ni20300900
part # ni20401080
part # 860400255
part # 860400270
part # ni20100215
part # ni870003204
part # 980400200
part # 20701070
part # 860400210
4
4
12
1
1
1
4
12
2
4
10
2
