IR Remote Control Function:
Volume Level
Control
Using the supplied IR Remote Control will give access to further features and functions of the AVID3 and
will allow adjustments to the sound levels and tone settings.
The LED display panel will show the settings as any adjustments are made as follows:
•
The overall volume level (0 lowest ~ 20 highest)
•
Bass (L.1 lowest ~ L.9 highest)
•
Treble (H.1 lowest ~ H.9 highest)
•
Balance (B.1 Fully Left ~ B.5 Centre ~ B.9 Fully Right)
After any changes have been made to the above, the LED display will revert to the set volume level.
Please ensure that the enclosed User Instructions are left with the AVID3 unit, easily available to the end
user.
CIE-Group Ltd 3 Widdowson Close Blenheim Ind Est Bulwell Nottingham NG6 8WB UK
T: +44(0)115 9770075 F: +44(0)115 9770081 E: info@cie-group.com W: www.cie-group.com
Bass Level
Treble Level
Control
Control
Power
ON/OFF
L/R Speaker
Balance
Function not enabled
on AVID3BT Model
Registered in England No. 2761780
Advertisement
Related Manuals for CIE-Group avid3
Summary of Contents for CIE-Group avid3
- Page 1 Function not enabled on AVID3BT Model Using the supplied IR Remote Control will give access to further features and functions of the AVID3 and will allow adjustments to the sound levels and tone settings. The LED display panel will show the settings as any adjustments are made as follows: •...
- Page 2 Before installation please take the time to read and understand the enclosed information. What’s included in the box? 1x AVID3 Amplifier, 1x 24v DC 1.25A PSU, 1x IR Remote Control Unit and 1 x Wallmount Bracket for Remote Control. Specifications:...
- Page 3 Before installation please remove the Facia Trim Plate from around the front edge of the unit. This can be refitted once the installation is finished and any decorating is completed. The compact depth of the AVID3 unit will allow installation into standard UK 2-gang EO boxes, with a minimum of 40mm depth.
- Page 4 L (Left Signal), G (Screen) and R (Right Signal). Important Information: It is important to note that if using the audio input loacated on the rear of the AVID3 that the signal applied is at full line level.
