CIE-Group AVID3ACBT Installation Manual

IR Remote Control Function:
Bass Level
Control
Volume Level
Control
Using the supplied IR Remote Control will give access to further features and functions of the AVID3ACBT
and will allow adjustments to the sound levels and tone settings.
The LED display panel will show the settings as any adjustments are made as follows:
• The overall volume level (0 lowest ~ 20 highest)
• Bass (L.1 lowest ~ L.9 highest)
• Treble (H.1 lowest ~ H.9 highest)
• Balance (B.1 Fully Left ~ B.5 Centre ~ B.9 Fully Right)
After any changes have been made to the above, the LED display will revert to the set volume level.
Please ensure that the enclosed User Instructions are left with the AVID3ACBT unit, easily available to the
end user.
CIE-Group Ltd 3 Widdowson Close Blenheim Ind Est Bulwell Nottingham NG6 8WB UK
T: +44(0)115 9770075 F: +44(0)115 9770081 E: info@cie-group.com W: www.cie-group.com
Treble Level
Control
Power
ON/OFF
L/R Speaker
Balance
Function not enabled
on AVID3BT Model
Registered in England No. 2761780
Installation Guide
Before installation please take the time to read and understand the enclosed information.
What's included in the box?
1 x AVID3ACBT Amplifier
1x IR Remote Control Unit & Wall Bracket
1 x 2-Gang EO Recessed Backbox

Specifications:

Output Power 2 x 15W @ 4W
Line Inputs Stereo 3.5mm Jack (Front panel)
2x Screw Terminal (Rear PCB)
Line Output Fixed level (Unbalanced) 1v 47kW
Bluetooth Wireless Bluetooth Receiver (secure Pairing Code)
Frequency Response 40Hz ~ 20KHz
Input Sensitivity (Lo) 200mv / (Hi) 1v
Power Requirements 230v AC
Dimensions 165(W) x 100(H) x 35(D) mm
Weight 0.26kg
www.cie-group.com
01/18
