- Page 1 Cart Model GS1504-C GS1504-C...
-
Page 2: Table Of Contents
Table of Contents SAFETY PRECAUTIONS ........................... 3 INSTALLATION INSTRUCTIONS ........................ 4 Inspection of Shipment ............................ 4 Manual ................................... 4 Items Included with this Unit .......................... 4 Setup – Cart Assembly ............................ 4 CARE AND CLEANING ............................ 6 MAINTENANCE INSTRUCTIONS ........................ 6 ORDERING SPARE PARTS .......................... 7 Cart ‐ Parts Breakdown . -
Page 3: Safety Precautions
SAFETY PRECAUTIONS DANGER Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury, or death. Any alterations to this equipment will void the warranty and may cause a dangerous condition. This appliance is not intended to be operated by means of an external timer or separate remote-control system. -
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS Inspection of Shipment After unpacking, check thoroughly for any damage which may have occurred in shipment. Purchaser should make claim directly to carrier for any damages to merchandise that occur in transit. The warranty does not cover damage that occurs in transit, or damage caused by abuse, or consequential damage due to the operation of this machine, since it is beyond our control (reference warranty in back of manual). Manual Read and understand the operator’s manual and all other safety instructions before using this equipment. To order copies of the operator’s manual contact Global Solutions, 301 Meuse Argonne Hicksville, OH 43526, 800.782.6761, or go to www.nemcofoodequip.com. Items Included with this Unit Base Cabinet Handle Bar and 2 Handlebar Brackets 2 Wheels 1 Axle 2 Short Axle Supports 2 Long Leg Supports 2 Leg Support Brackets 2 Adjustable Feet (for long legs) Hardware Kit (includes door knob) Setup – Cart Assembly This cart requires assembly (units with a door, come with the door and magnet pre‐assembled to the base). Remove all packaging and tape, then follow the steps below for cart assembly. - Page 5 Step 2: Attach axle assembly to base on the Figure C ‐ Install side opposite the handlebar (Figure B). Use an Adjustable Foot 2 long bolts, 4 washers, and 2 lock nuts on on each leg. each support (use a washer on each end). Once assembled, tighten the axle nuts to secure. Leg Support Attach Axle (long) Assembly Step 3: Assemble long legs to base. Fasten each leg using 2 long bolts, Leg Support 4 washers, and 2 lock nuts. Bracket Step 4: Position the leg support bracket as shown in Figure B. Fasten bracket to leg using a long bolt, washer, and lock nut. Fasten bracket to cabinet using a short bolt, washer, and lock nut. Figure B – Attach Axle Assembly and Legs Step 5: Install an adjustable foot onto each long leg. Ensure foot is fully inserted in leg as Lock Nut shown in Figure C. Step 6: Slide a wheel onto each end of the axle and fasten with a lock nut (Figure D). Tighten the lock nut enough to take up clearance. DO NOT overtighten. Step 7: Position cart upright, and ensure all fasteners are secure. Figure D Step 8: Assemble a bracket on each end of the handlebar. Fasten handle assembly to Door Knob Handle Assembly cabinet using 4 short bolts, 4 washers, and...
-
Page 6: Care And Cleaning
CARE AND CLEANING Good sanitation practice demands that all food preparation equipment be cleaned regularly (only use non‐toxic, food grade cleaners). A clean looking, well‐kept machine is one of the best ways of advertising your product. Follow the directions below to clean and sanitize unit each day after use. 1. Wipe unit with a soft cloth, dampened with hot water. DO NOT use abrasive materials on this unit. 2. If further cleaning is needed, use Watchdog Concession Equipment Cleaner. MAINTENANCE INSTRUCTIONS DANGER Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury, or death. Any alterations to this equipment will void the warranty and may cause a dangerous condition. This appliance is not intended to be operated by means of an external timer or separate remote-control system. -
Page 7: Ordering Spare Parts
ORDERING SPARE PARTS 1. Identify the needed part by checking it against the photos, illustrations, and/or parts list. (General images may be used in manual for reference only.) 2. Use only approved replacement parts when servicing this unit. 3. When ordering, please include part number, part name, and quantity needed. 4. Please include your model number, serial number, and date of manufacture (located on the machine nameplate/data plate) with your order. 5. Place orders by phone or online: Phone: 800.782.6761 Fax: 419.542.6690 Web Page: www.nemcofoodequip.com ... -
Page 8: Cart - Parts Breakdown
Cart - Parts Breakdown Part Number Item Part Description GS1504‐C HANDLE BAR CART GOLD 10423 BRACKET HANDLE BAR GOLD (2 required) 10422 MANUAL 10435 ... -
Page 9: Product Warranty
PRODUCT WARRANTY PRODUCT SERVICE TERMS & CONDITIONS ... - Page 10 MODEL NUMBER CROSS REFERENCE Global Solutions Gold Medal Products Co. GS1504-C 2649-00-015 Approvals / Listings for Global Solutions Carts: Our carts are manufactured to Global Solutions (a Nemco Food Equipment Company) specifications by Gold Medal Products Co., USA. 110195 3/29/18 ...
