2-4 Other Adjustments
2-4-1 Screen Adjustment
1. Warm up the TV for at least 30 minutes.
2. Select the "STANDARD" Video mode.
3. Trun to the Video Mode(No Signal) using a
remote-control.
4. Connect an oscilloscope to RK, GK, BK.
5. Adjust the VR (Focus Pack) screen so that RK,
GK, BK pulse is 20Vp-p each. (Turn the R,G,B
VR screen fully counterclockwise in the area of
each flyback line.)
2-4-2 White Balance Adjustment
1. Select the "STANDARD" video mode.
2. Input 100% white pattern.
3. In the stand-by mode, press the remote-control
keys in the following sequence:
Displsy → Menu → Mute → Power ON
4. Warm up the TV for at least 30 minutes.
5. Input a 10-step signal.
6. R-cut off, B-cut off, and G-cut off by pressing
the Direction
7. Adjust the low light with viewing the dark
side of the screen.
8. Select R-drive, G-drive and B-drive by
pressing Direction
9. Adjust the high light with viewing the light
side of the screen.
10. If necessary, redo adjustments 6~9.
11. Press the Menu key to exit.
2-4-3 Sub-Brightness Adjustment
1. Input a sub-brightness adjustment signal.
(TOSHIBA PATTERN)
2. In the stand-by mode, press the remote-control
Samsung Electronics
keys.
keys.
keys in the following sequence :
Info -> Menu -> Mute -> Power ON
3. Select Sub-Bright by pressing the Deletion
Keys.
4. Adjust so that the 63 step on the right side of
the screen is not seen (Use the
5. Press the Menu key to exit.
2-4-4 High Voltage (29KV) Check
PRECAUTION
1. Input a lion head pattern.
2. Select "STANDARD" video mode.
3. Warm up the TV for at least 10 minutes.
4. Use a 1000:1 probe.
ADJUSTMENT
1. Connect the (+) terminal of the 10000:1 probe
to the high voltage distributor and the(-)
terminal to GND(located on the deflection
board).
2. Adjust RR471S (located on the deflection
board) so that the digital meter indicates
DC29V ± 0.1V.
2-4-5 F.S. (Fail Safe) Circuit Check
Note : The finished product has a well-mounted
VR(RR402S).
If necessary, do the F.S adjustments in the
following sequence.
1. Use a digital multimeter.
2. Connect the digital multimeter to the JIG pin
(DZ482S) terminals.
3. Adjust VR(RR402S) so that the voltage
becomes 2.25V.
4. After the adjustments are complete be sure to
mount VR(RR402S) correctly.
1-4-6 Static Focus Adjustment
