LIGHT MY BRICKS: LEGO 1989 Batmobile 76139
Lighting Kit
The following page is the instructions for the
Light My Bricks LEGO 1989
Batmobile (76139) LED light kit.
If you run into any issues, please refer to the
online troubleshooting guide.
To ensure a trouble-free installation of your light kit, please read and follow
each step carefully. These instructions can be downloaded in PDF format
here
Please note: This page lists instructions for the LED light kit only. If you are
wishing to purchase the Light My Bricks LEGO 1989 Batmobile (76139) LED light
kit , please click
here
to view the product page
