To go from one menu to the next, push the MENU button.
.
PowerMaster II RF Wattmeter
Coupler Type
Push the mode select button to select the type of coupler
connected to Coupler 1 input:
3KW
10KW
VHF-1
VHF-2
UHF
QRP-HF
Note: If Coupler 2 was active, you would see the same
options for Coupler 2. More on couplers selection later.
VSWR Alarm Limit Menu
Push the mode select button to select the VSWR alarm trip
point:
Push the mode select button to reset the VSWR alarm and
LED
www.arraysolutions.com
(Coupler 1 shown)
(C1 – Coupler 1)
Off
1.5
2.0
2.5
3.0
