- Page 1 DVI Distributor (2 way) ID #392 Operation Manual...
- Page 2 Introduction The DVI Distributor (2 way) is 1 -input -2 -output digital DVI distribution amplifier based on panel link technology. It accepts a DVI signal from a computer and splits up to two identical and buffered outputs. Each of the outputs can run up to 15 meters using a standard DVI cable.
- Page 3 Specifications Input/Output: 1 input / 2 output Bandwidth: 26~165MHz Voltage: AC 100 to 240 DC 5V 2A out Power Consumption: 6W Max Operating Temperature Range: 5 to 40 degrees Operating Humidity Range: 30 to 80% RH Dimensions(mm): 142(W)x130(D)x38(H) Weight: approx. 1.5kg Installation...
- Page 4 DVI-D Pin Configuration DVI-Digital (DVI-D): Supports display-only connections between the host computer and display. This interface is designed for a 12 or 24-pin connection to enable single or dual-link mode activation. DVI-D Recepticle Connector...
