- Page 1 HDMI to HDMI Scaler Box - # 15405 Operation Manual...
- Page 2 Introduction The HDMI to HDMI Scaler is designed to upscale an HDMI video signal from an HDMI source device and output in a wide range of HDTV and PC resolutions up to 1080p/WUXGA. Additionally this unit can also convert a digital/analog audio signal and then simultaneously output to an HDMI, Optical and 3.5mm Mini-jack (L/R audio) connections.
- Page 3 HDMI OUTPUT: Connect to a HDMI equipped display or AV receiver for video and audio output. OPTICAL OUTPUT: Connect to an amplifier or active speakers with an optical cable for LPCM 2 channel digital audio output. AUDIO OUTPUT: Connect to an amplifier or active speakers with a 3.5mm mini-jack cable for analog audio output.
- Page 4 DC 5V: Connect the 5V DC power supply to the unit and plug the adaptor into an AC outlet. Power LED: This LED will illuminate once the unit is connected to an active power supply. OSD Menu Main Menu Layer Layer Picture Setting Contrast...
- Page 5 Exit OSD Setting H-Position 0~100 (10) V-Position 0~100 (90) Timer 0~100 (50) Background 0~100 (50) Display INFO, ON, OFF (INFO) Exit Factory Reset Information Exit Note: Values in brackets are default for that setting. Supported Resolutions Resolution Input Output 640×480@60/72/75/85Hz √...
- Page 6 Specifications Video Bandwidth 225MHz/6.75Gbps Input Ports 1×HDMI, 1×3.5mm Mini-jack, 1×Optical (TOSLINK), 1×USB (Service only) Output Ports 1×HDMI, 1×3.5mm Mini-jack, 1×Optical (TOSLINK) HDMI Output Resolutions Up to 1080p & WUXGA@60 (RB) HDMI and Optical Audio Sampling Rates Up to 48kHz Power Supply 5V/2.6A DC (US/EU standards, CE/FCC/UL certified) ESD Protection...
- Page 7 Connection Diagram...
