Summary of Contents for Bowers & Wilkins SA250 Mk2
- Page 2 Welcome and thank you for choosing Bowers & Bienvenue et merci d’avoir choisi Bowers & Wilkins. Wilkins. Our founder, John Bowers, believed that imaginative Notre fondateur, John Bowers, était persuadé qu’une design, innovative engineering and advanced technology conception imaginative, des innovations en termes were keys that could unlock the enjoyment of audio in the d’ingénierie et des technologies parmi les plus avancées, home.
- Page 3 Köszönjük, hogy a Bowers & Wilkins-t választotta. Καλώς ήρθατε, σας ευχαριστούμε που επιλέξατε ένα προϊόν της Bowers & Wilkins. Ο ιδρυτής μας John Amikor John Bowers megalapította a társaságot, célja az volt, hogy az ötletes dizájn, innovatív megoldások Bowers, πίστευε πως η ευφάνταστη σχεδίαση, οι és fejlett technológia révén tökéletesítse az otthoni καινοτόμες...
-
Page 4: Carton Contents
Thank you for choosing Bowers & Wilkins. In addition to the amplifier itself, check in the carton for: The SA250 Mk2 is designed to power and apply the 1 x Power cable correct equalisation to the ISW-3 and ISW-4 custom install subwoofers. -
Page 5: Installation
Rack Mounting The SA250 Mk2 is supplied with two rack mounting brackets for installation in standard equipment racks (above). Attach the brackets by inserting three of the short Philips head machine screws through each bracket into the threaded... -
Page 6: Controls And Connections
4. Controls and Connections ISW-3 ISW-4 Rear Panel Sockets and Switches (above) Front Panel Controls (below) Unbalanced Line In and Link Out sockets (RCA Phono) Power: Illuminates to indicate the amplifier is switched on. Balanced Line In and Link Out sockets (XLR) Fault: Illuminates to indicate a fault condition. - Page 7 Connection to the subwoofer(s) In all cases, observe the correct polarity connections. A single SA250 Mk2 can drive one or two identical Incorrect connection will result in a poor imaging and/or a subwoofers in parallel. If you need more than two subwoofers loss of bass output.
- Page 8 Connection to a surround processor If only unbalanced connection is available, use RCA Phono Connect the LFE or Subwoofer output of the processor to a connectors and the left channel input of the SA250 Mk2 Line In socket of the SA250 Mk2. (above).
- Page 9 You can combine both left and right channels into one or frequencies by having a subwoofer for each channel, you will two subwoofers using a single SA250 Mk2. In this case, only need a second SA250 Mk2. In this case, if the pre-amplifier unbalanced connection is possible (above).
-
Page 10: Setting The Controls
6. Setting the controls ISW-3 ISW-4 On the Rear Panel Home Theatre Subwoofer Equalisation Set the LOW-PASS FILTER switch (4) to Off. Set the subwoofer switch (5) on the rear panel to the appropriate model. The setting of the FREQUENCY (5) control is now irrelevant. On the Front Panel Set the BASS EXTENSION switch (6) initially to A. -
Page 11: Channel Audio
7. Fine Tuning 2-channel Audio Before fine tuning, make sure that all the connections in the Set the LOW-PASS FILTER switch (4) to On. installation are correct and secure. Set the FREQUENCY control (5) to match the -6dB low Home Theatre frequency cut-off frequency of the satellite speakers. -
Page 12: All Applications
2-channel Audio All Applications Set the system up in the preferred position and play some The BASS EXTENSION switch offers three options of material with a steady bass content. subwoofer bass extension. Position A gives the greatest extension and position C gives the least extension. Position The optimum settings of the PHASE switch and the B provides a compromise setting. -
Page 13: Standards Conformity
Complies with Part 15 of the FCC Rules Operation is subject to the following conditions: 1. This device does not cause harmful interference and 2. This device must accept any interference received, including interference that may cause undesired operation. SA250 Mk2... - Page 15 Powered by a separate audiophile- standard 250W Class D amplifier the SA250 Mk2, the system keeps its cool even when the music movie action is whipping up a storm.
- Page 16 Custom Installation SA250 Mk2 SA250 Mk2 Technical Specifications Description 250W rack-mount amplifier with built- in subwoofer equalisation Amplifier inputs - 2x RCA Phono socket, line in - 2x RCA Phono socket, link out - 1x XLR socket, line in - 1x XLR socket, link out - 3.5mm jack - 12V trigger on/standby...
