  • Page 1 IW-RF100S User’s Manual...
  • Page 2: Table Of Contents

    Table of Content PREFACE SAFETY INFORMATION SPECIFICATIONS 1 Product Introduction Box Content General Information 1.2.1 Front Panel Controls and Indicators 1.2.2 Rear Panel Configuration 2 Hardware Installation Removing and Installing a Hard Drive 2.1.1 Installing a Hard Drive 2.1.2 Removing a Hard Drive Removing and Installing Top Cover P.10 Removing and Installing a Fan Module...
  • Page 3: Preface

    In Win’s server website to download the latest updated version. SAFETY INFORMATION To ensure safe and smooth operation of your In Win IW- RF100S, it is essential that you choose an appropriate location for the system, provide an appropriate operating environment, and adequate power for all components of the system.
  • Page 4 Installing or removing jumpers: A jumper is a short length of conductor used to close, open or bypass part of an electronic circuit. Jumpers on In Win backplane have a small tab on top that you can pick up with your fingertips. Grip the jumper carefully, and plug the jumper to cover the jumper pins on the backplane.
  • Page 5: Specifications

    SPECIFICATIONS Model Name IW-RF100S Standard EIA-RS310D M/B Form Factor MINI ITX (6.7“ x 6.7“) Dimensions (D x W x H) 250 x 482.6 x 44 mm (9.8“ x 19” x 1.75”) Internal: 2.5" HDD x 2 Drive Bay 3.5” HDD x 2 (Optional 2.5” HDD x 4)
  • Page 6: Product Introduction

    1 Product Introduction Box Content When you open the carton box of IW-RF100S, the contents should include: - 5 -...
  • Page 7: General Information

    General Information When you open the top cover should be like the diagram shows bellow. 2 x 3.5” HDD tray Top cover Mini-ITX or ATX Single module power supply Front Controls PWM Fan x 2pcs and indicators (max to 3 pcs) - 6 -...
  • Page 8: Front Panel Controls And Indicators

    1.2.1 Front Panel Controls and Indicators The front control panel includes USB IO ports and indicator LED lights. Name Color Status Description USB3.0 Connector No LED function USB devices connection Solid on System is powered on Power ON/OFF Button Blue System is not powered on Power LED No LED function...
  • Page 9: Rear Panel Configuration

    1.2.2 Rear Panel Configuration The rear side of IW-RF100S contains the space of AC power source, system IO, and an expansion cards slot. Name Description This window is for installing single PSU, please reference In-Win Power Supply Window compatibility list to select the compatible models.
  • Page 10: Hardware Installation

    2 Hardware Installation Removing and Installing a Hard Drive In Win IW-RF100S has two 3.5” disk cages, each supports installing a 3.5” hard drive, and stacking a 2.5” drive. 2.1.1 Installing Hard Drive Step 1: Loosen the thumb screw and pull backward to remove disk cage.
  • Page 11 Removing and Installing the fan wall The fan module of IW-RF100S is tool-less design with easy swap feature. Removing the fan wall before posting the motherboard to get more space for the processing. 2.3.1 Removing the fan wall Step 1: Unplug the fans’...
  • Page 12: Installing Slide Rail

    2.5 Installing a Slide Rail In Win IW-RF100 is a rackmount model, which support EIA-RS310D standard cabinet and chassis rack. In Win provides standard slide rail to let users mount the chassis on to the cabinet. 2.5.1 Identifying the sections of the Slide Rail 2.5.2 Installing a Slide Rail...
  • Page 13: Installing Motherboard

    IO window 1.2.2 shows. If you cannot find the IO shield, please check with your motherboard vendor, or contact In Win for IO shield production service. Step 1: Measure the motherboard location and removing the plastic dots to appear the holes.
  • Page 14: Connecting Cable

    2.2.1 Connecting LED cable, front control panel and front USB IO ports As 1.2.1 descripts, In Win IW-RF100S built-in a set of front control panel and USB access ports. You need to connect to the pins on the motherboard to active the functions. The pin function and location you can find from your motherboard’s user guide.
  • Page 15: Compatibility Lists

    2. Do the chassis support mirrored OS disks? You can mirror any two hard drives, such as IW-RF100’s two 2.5” hard drives, or IW-RF100S’ two 3.5” and two 2.5” drives. Yet, the disk mirroring is defined by your motherboard or your RAID 1 controller card.
