- Page 1 IW-RS316-02M User’s Manual...
-
Page 2: Table Of Contents
Table of Content PREFACE SAFETY INFORMATION SPECIFICATIONS 1 Product Introduction Box Content General Information 1.2.1 Front Panel Controls and Indicators 1.2.2 Rear Panel Configuration 2 Hardware Installation Removing and Installing a Hard Drive 2.1.1 Installing a Hard Drive 2.1.2 Removing a Hard Drive Removing and Installing Top Cover P.10 Removing and Installing a Fan Module... -
Page 3: Preface
In Win’s server website to download the latest updated version. SAFETY INFORMATION To ensure safe and smooth operation of your In Win IW- RS316-02M, it is essential that you choose an appropriate location for the system, provide an appropriate operating environment, and adequate power for all components of the system. - Page 4 Installing or removing jumpers: A jumper is a short length of conductor used to close, open or bypass part of an electronic circuit. Jumpers on In Win backplane have a small tab on top that you can pick up with your fingertips. Grip the jumper carefully, and plug the jumper to cover the jumper pins on the backplane.
-
Page 5: Specifications
SPECIFICATIONS Model Name IW-RS316-02M Standard EIA-RS310D M/B Form Factor ATX (12” x 9.6”), ATX(12” x10”), EEB(12” x 13”) Dimensions (D x W x H) 625 x 482.6 x 131 mm (24" x 19" x 5.25") External: Slim ODD x 1, Hot-Swap 3.5" x 16 or 2.5" x 16, Drive Bay 2.5"... -
Page 6: Product Introduction
1 Product Introduction Box Content When you open the carton box of IW-RS316-02M, the contents should include:... -
Page 7: General Information
General Information When you open the top cover should be like the diagram shows. Top cover ATX or EEB M/B CRPS or Single module power supply Slim ODD installation Max. PWM Fan (3pcs) 16 x 3.5” HDD tray Front Controls and indicators 2 x 2.5”... -
Page 8: Front Panel Controls And Indicators
1.2.1 Front Panel Controls and Indicators After unlock and removing the front cover, you can see the 16 disk bays, and the control panel, USB IO ports and indicators on the handles. Name Color Status Description Press the button to activate system 1 Chassis ID Button with LED Blue Solid on... -
Page 9: Rear Panel Configuration
1.2.2 Rear Panel Configuration The rear side of IW-RS316-02M contains space of AC power source, system IO, and an expansion cards slot. Name Description The bracket is for holding single PSU. For redundant PSU, remove this cover PSU Bracket and replace as redundant PSU housing case bracket. -
Page 10: Hardware Installation
Removing and Installing a Hard Drive In Win IW-RS316-02M has 16 external hot-swap disk bays, which support both 3.5” hard drives, 2.5” hard drives, and 2.5” SSDs. Also, IW-RS316-02M supports 4 internal 2.5” hard drives or SSDs for building system OS. -
Page 11: Removing A Hard Drive
2.1.2 Removing a Hard Drive Step 1: Press the release button then pull outward the disk tray. Step 2: Loosen the 4 screws and unmount the hard drive. Step 1 Press Release HDD tray Step 2 Pull Unscrew 2.1.3 Installing 2.5” 2bay SSD module Step 1: Remove the slot bracket to left the space for the module. - Page 12 Step 4: Push forward the cover and make sure the clip clicks, then screw up to fix the cover. Removing and Installing the fan wall The fan module of IW-RS316-02M is flexible which you can move forward or backward to optimize the cooling efficiency. Removing the fan wall before posting the motherboard to get more space for the processing.
- Page 13 Step 2 Loose the thumb screw 2.3.2 Moving and installing the fan wall (Repeat the actions of 2.3.1)Step 1: Loosen the thumb Step 1 Install the fan wall Step 2 into the chassis...
-
Page 14: Removing And Installing A Psu Module
Removing and Installing a PSU In Win IW-RS316-02M supports single and redundant power supply unit. Users can select power supply according to the environment’s requirements. Note: The different PSU needs different rear and side bracket. The accessory box includes the bracket sets for supporting models. -
Page 15: Installing Slide Rail
2.5 Installing a Slide Rail In Win IW-RS316-02M is a rackmount model, which support EIA-RS310D standard cabinet and chassis rack. In Win provides standard slide rail to let users mount the chassis on to the cabinet. 2.5.1 Identifying the sections of the Slide Rail 2.5.2 Installing a Slide Rail... -
Page 16: Installing Motherboard
IO window 1.2.2 shows. If you cannot find the IO shield, please check with your motherboard vendor, or contact In Win for IO shield OEM service. Step 1: Measure the motherboard location and removing the plastic dots to appear the holes. -
Page 17: Connecting Cable
2.7.2 Connecting LED cable, front control panel and front USB IO ports As 1.2.1 descripts, In Win IW-RS-02M built-in a set of front control panel and USB access ports. You need to cover the connectors to the pins on the motherboard to active the functions. -
Page 18: Backplane Introduction
To reach best performance and avoid system failure, In Win strongly recommend users choosing the components from In Win’s compatibility list. All the components are tested in In Win’s lab and assured the components are working well with In Win’s chassis. - Page 19 Does backplane supports 6Gb SAS? A: In Win IW-RSXXX-02M in default is with 12Gb SAS backplane. The 12Gb SAS connector is not alignment with 6Gb SAS. In Win provides OEM/ODM service, user can contact In Win sales for customization.
- Page 20 Where can I buy the SAS cable? 6Gb SAS to 4 SATA or 6Gb SAS to 6Gb SAS are standard cable that you easily buy from many vendors. You can buy the verified cable from In Win to eliminate the compatibility issues.
