BUILT-IN GAS HOB
Operating & Installation Instructions
-Please keep for future reference
AG60GNSS
AG60GNW
Important -
Please read these instructions fully before using
These instructions contain important information which will help you get the best from your
appliance and help to ensure safe and correct installation, use and maintanence.
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 257 7271
Advertisement
Related Manuals for Bush AG60GNSS
Summary of Contents for Bush AG60GNSS
- Page 1 BUILT-IN GAS HOB Operating & Installation Instructions -Please keep for future reference AG60GNSS AG60GNW Important - Please read these instructions fully before using These instructions contain important information which will help you get the best from your appliance and help to ensure safe and correct installation, use and maintanence.
-
Page 2: Table Of Contents
Contact your nearest authorised service agent for installation of your appliance. DESCRIPTION OF THE HOB Medium burner Rapid Burner Auxillary burner Product code AG60GNSS AG60GNW... -
Page 3: Safety Information
Safety Information Customer Helpline 0345 257 7271 Important - Please read these instructions fully before installation READ THESE INSTRUCTIONS CAREFULLY AND switch off the appliance and then COMPLETELY BEFORE USING YOUR cover flame e.g. with a lid or a fire APPLIANCE, AND KEEP IT IN A CONVENIENT blanket. - Page 4 Safety Information Customer Helpline 0345 257 7271 Important - Please read these instructions fully before installation IMPORTANT- Prior to installation, ensure that the authorized technician and put into use. The local distribution conditions (nature of the gas and producer is not responsible for any damage that gas pressure or electricity voltage and frequency) might be caused by defective placement and and the requirements of the appliance are...
- Page 5 Safety Information Customer Helpline 0345 257 7271...
-
Page 6: Installation
Installation Customer Helpline 0345 257 7271 CAUTION! THIS APPLIANCE MUST ONLY BE INSTALLED BY A <GAS SAFE> REGISTERED ENGINEER. Remember that this appliance is ready to be connected to a gas supply in the country for which it has been produced. The main country of destination is marked on the rear cover of the appliance. - Page 7 Installation Customer Helpline 0345 257 7271 - 100mm from the edge of the cooker to any combustible materials. - 700mm underneath any overhead cupboards or shelving - 750mm underneath any overhead extractor fans. Apply the self adhesive seal to all edges of the cutout and carefully fit the hob into the opening in such a way that the knobs will be right side.
- Page 8 Installation Customer Helpline 0345 257 7271 The wires in the mains lead on this appliance are coloured in accordance with the flowing code: Green and Yellow - Earth Blue - Neutral Brown - Live? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? As the colours may not correspond with the markings identifying the terminals in your plug proceed as follows.
-
Page 9: User Instructions
User Instructions Customer Helpline 0345 257 7271 Using Your Gas Hob Injectors replacement To ignite one of the burners, approach a match, This appliance is manufactured so that it is taper or another manual aid to its upper capable of conversion to LPG. circumference and push the corresponding Select the injectors to be replaced according to control knob and turn it counter clock-wise. - Page 10 User Instructions Customer Helpline 0345 257 7271 Make sure that the tips of the flames do not spread out of the outer circumference of the pan, as this may also harm the plastic accessories around the pan (handles etc.) When the burners are not in use for prolonged periods, always turn the main gas control valve off.
-
Page 11: Maintenance & Care
Maintenance & Care Customer Helpline 0345 257 7271 Cleaning: Before cleaning disconnect the hob from the electricity supply. Burner Caps: Periodically, the enamelled pan supports, , enamelled covers and burner heads must be washed with soapy warm water rinsed and dried. After drying them thoroughly, replace them correctly. -
Page 12: Injector Table
Injector Table Customer Helpline 0345 257 7271 G30 28-30mbar 7.5 kW 545 g/h G30/G31 II2H3+ GB Clase: 3 G20 20 mbar 28-30/37 mbar LARGE BURNER DIA. of INJECTOR (1/100mm) NOMINAL RATING (KW) CONSUMPTION 285,7 l/h 218,1 g/h MEDIUM BURNER DIA. of INJECTOR (1/100mm) NOMINAL RATING (KW) 1,75 1,75... - Page 13 Technical Specifications Customer Helpline 0345 257 7271 Model/Item AG60GNSS - Inox AG60GNW - White Power supply (230)V~/50 Hz (230)V~/50 Hz Maximum power 7,5 Kw 7,5 Kw Size(H x W x D) 39x580x510 mm 39x580x510 mm Cut-Out Dimensions(W x D) 560x490 mm...
- Page 14 Customer Helpline: 0345 257 7271. 52136281 05/15 R002 52136281 R001 11/14...
