INSTRUCTION,
USE & CARE MANUAL
Models UC-PS16-30 | UC-PS16-36

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the chef Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hauslane chef Series

  • Page 1 INSTRUCTION, USE & CARE MANUAL Models UC-PS16-30 | UC-PS16-36...
  • Page 2: Table Of Contents

    INJURY, OBSERVE THE FOLLOWING: may ignite. 1. Use this range hood only in the manner intended by the manufacturer. If you have the questions, contact HAUSLANE 2. Heat oils slowly on low or medium settings. at 1-800-929-0168 or email at info@hauslane.com.
  • Page 3: Warranty Information

    24"; any installation less than 24" may cause overheating and cause 8. Please read product specification label on range hood damage to the range hood, HAUSLANE does not warrant for further information and requirements. this improper installation.
  • Page 4: Specifications

    Specifications Dimentions UC-PS16-30 Dimentions UC-PS16-36 Volts Hertz Fan CFM Speeds Light Wattage Stainless Steel Grade 29- 3 /4" W 35- 3 /4" W 22" D 22" D 3W x2 8"H 8"H Package Contents Hood Round Adapter (Preinstalled) Vertical Rectangular Adapter Horizontal Rectangular Adapter Bag of screws (AA) 2 x 3Watts LED Light...
  • Page 5: Preparation: What To Do Before Installation

    Preparation: What to Do Before Installation Before installing your range hood, carefully follow these steps: -------­ -------- External ro External ro � ! � ! cap by othe cap by oth • 1. Read This Manual > > Read through all the steps. If you fail to read the instructions carefully, we will not be responsible for damages incurred on your part.
  • Page 6: Prepare The Cabinet (Soffit)

    Is it a 6" round duct? You won't have to make any extra preparations. The range hood will attach directly to your duct. Be sure to remove the tape holding up the dampers. & Failure to remove the tape from the damper IMPORTANT: will cause reduction in performance.
  • Page 7 UC-PS16-30 1. Round Vertical Adapter □ □ Cabinet with recessed bottom Cabinet or soffit with flush bottom ' --- - - 30" cabinet(typical) _ _ _ _., , - - 30" cabinet(typical)-- ___., flush bottom Cabinet w ith '------- 1"hole 6-1/2"hole�...
  • Page 8 3. Rectangular Horizontal Adapter □ D □ □ Cabinet with recessed bottom Cabinet with flush bottom ..-- - - 30" cabinet(typical)- - - --..-- - - 30" cabinet(typical) - - - � L_J L_J • • Cabinet w it h Cabinet w i th recessed bottom ~...
  • Page 9 UC-PS16-36 1. Round Vertical Adapter Cabinet with recessed bottom Cabinet or soffit with flush bottom i l+---- ---36" cabinet(typica l) - -- � 1+-------36" cabinet(typical) ---+< □□ □□ Cabinetwith Cabinet with � bottom flush � ottom 1"hole 1"hole 6-1/2"hole� 6-1/2"hole� 12"...
  • Page 10 3. Rectangular Horizontal Adapter □ □ □ □ Cabinet with recessed bottom Cabinet with flush bottom t4-- - -36" cabinet(typical) - - - � t<----- - 36" cabinet(typical) - - - � LJ LJ Cabinet w it h Cabinet w it h �ce�bottom flushbottom �...
  • Page 11 Ductless Version How to Install the Charcoal Filter NOTE:The charcoal filter should only be installed if you are not using an external venting system HOUSEWRIING CABINET-- 1. Turn over the range hood (A) and place its top on a protective surface . 2.
  • Page 12: How To Install Your Range Hood

    If the range hood is not working properly, IMPORTANT: please contact us immediately (1-800-929-0168 I info@hauslane.com). 2. Uninstall the Range Hood's Bottom Cover Remove the filter from the hood by pushing the filter knob inward . Slowly pull the filter down and remove gently from the range hood.
  • Page 13: Double-Check Installation & Remove Support

    5. Double-Check Installation and Remove Support 7. Plug the Range Hood In Be sure that the hood is securely attached before removing Plug the power cable into an outlet. the cabinet jacks and plywood. 6. Connect Damper & Check for Airtightness Turn on the hood to make sure that the damper opens and closes freely.
  • Page 14: Basic Maintenance Lnstructions

    Basic Maintenance Instructions Your range hood requires some easy routine maintenance to Maintaining the Lighting keep it running efficiently. This range hood uses two lamps of 3W. Maintaining the Filter 1. Turn off power. For halogen lights, let light bulbs cool Clean the grease filters frequently-we suggest cleaning every completely before removing, if needed (about 5 2 weeks.
  • Page 15: Wiring Diagram

    Wiring Diagram lamp high stop key switch :,.,:: >- � ..:i -< ..:i i::c:l � � p:::; >- i:.:: � p:::; i::i:i i:i:i BLACK ::.::: ::.::: :,.,:: >- � < < � -< ..:i ..:i p:::; p:::; i::i:i i::i:i i::i:i <;!) i:i:i �...
  • Page 16: Troubleshooting Tips

    10 seconds, and plug the power cord back. 2. If Step 1 doesn't resolve the issue, please contact us immediately for a control panel replacement. 1-800-929-0168 Still experiencing problems after following these steps? Contact a technician to assist. Contact us at or info@hauslane.com. UC-PS16 USER MANUAL...
  • Page 17: Contact Hauslane

    Contact Hauslane Extended Warranties If you are interested in an extended warranty, sign up on our website at www.hauslane.com Parts and Accessories If you need replacement parts or accessories, visit www.hauslane.com Contact Us We'd be happy to answer your questions or resolve any issues you may have.
