Controls

OSD (On-Screen Display) control keys on the front of the monitor function
are as follows:
To access OSD menu, touch any of the control keys.
To change signal input, touch the SELECT key.
NOTE: Exit OSD in order to change signal input.
1 Ambient Light Sensor
Human Sensor
2 INPUT/SELECT
3 MENU/EXIT
4 LEFT/RIGHT
5 UP/DOWN
6 ECO/RESET
7 Power
8 Power LED
* When Hot Key function is OFF, this function is disabled.
1
ECO TOOLS
BRIGHTNESS
Adjusts the overall image and background screen brightness.
If ECO MODE is set to 1 or 2, a bar for CARBON FOOTPRINT will appear.
CONTRAST
Adjusts the overall image and background screen brightness by input signal level.
NOTE: CONTRAST and DV MODE can be adjusted when other than L/B is selected for COLOR CONTROL.
Detects the level of ambient lighting and the presence of a user, allowing the monitor to
make adjustments to various settings resulting in a more comfortable viewing experience.
Do not cover this sensor.
Enters the OSD menu. Enters OSD sub menus.
Changes the input source when not in the OSD menu. You can directly change to L/B
(LOW BLUE LIGHT) mode by touching the INPUT key for 3 seconds or more.
Accesses OSD menu. Exits the OSD sub menu. Exits OSD menu.
Navigates to the left or right through the OSD menu.
Navigates up or down through the OSD menu.
You can adjust the BRIGHTNESS directly by touching UP while the OSD menu is off.*
You can adjust the VOLUME directly by touching DOWN while the OSD menu is off.*
Resets the OSD controls back to factory settings. Switches among ECO MODE settings.
Activates the Auto Adjust function if held for 3 seconds while the OSD menu is off
(analog input only)* .
1
Turns the monitor on and off.
Indicates that the power is on or off.
English-14
