4
60
Adjust the rear shock ab-
sorber, using a screwdriver
to turn adjusting screw 1.
z
If you want a harder damp-
ing characteristic, use a
screwdriver to turn adjust-
ing screw 1 in the direction
indicated by the H arrow.
If you want a softer damp-
ing characteristic, use a
screwdriver to turn adjust-
ing screw 1 in the direction
indicated by the S arrow.
Rear suspension, ba-
sic setting
One-up, rider weighing
85 kg
Turn the adjusting screw
as far as it will go in the
direction indicated by the
H arrow and then turn it
back one and a half turns
in the direction indicated
by the S arrow.
Electronic Suspension
Adjustment ESA
Settings
Electronic Suspension Ad-
justment ESA provides a con-
venient way of adapting the
motorcycle to different condi-
tions.
Three spring preload set-
tings can be combined with
three damping character-
istics to fine-tune the mo-
torcycle's suspension to the
load it carries and the surface
over which you want to ride.
The damping characteristic is
OE
