Instrument cluster

2
1 Warning and telltale
lights ( 24)
18
2 Speedometer
3 Control, clock (
4 Multifunction display
( 22)
5 Control, odometer
( 45), Field for warnings
( 24)
6 Telltale light, anti-theft
alarm (OE), Sensor for in-
strument cluster lighting
7 Rev. counter
z
The instrument-cluster
lighting has automatic
day and night switchover.
50)
