Transcend Compact Flash Card CF 266X Specification Sheet page 28

T
S 2 G ~ 8 G C F 2
T S 2 G ~ 8 G
C F 2
T S 2 G ~ 8 G C F 2
Notes: 1) All timing measurement switching points (low to high and high to low) shall be taken at 1.5 V.
2) All signal transitions for a timing parameter shall be measured at the connector specified in the
measurement location column. For example, in the case of tRFS, both STROBE and –DMARDY
transitions are measured at the sender connector.
3) The parameter tCYC shall be measured at the recipient's connector farthest from the sender.
4)The parameter tLI shall be measured at the connector of the sender or recipient that is
responding to an incoming transition from the recipient or sender respectively. Both the incoming
signal and the outgoing response shall be measured at the same connector.
5)The parameter tAZ shall be measured at the connector of the sender or recipient that is driving
the bus but must release the bus the allow for a bus turnaround.
Transcend Information Inc.
6 6
6 6
6 6
28
266X CompactFlash Card
