  • Page 1 ™ ExtremeWireless WiNG AP7662i/AP7662 Access Point Installation Guide 9035168-02 Published October 2018...
  • Page 2 Copyright © 2018 Extreme Networks, Inc. All rights reserved. Legal Notice Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.
  • Page 3: Table Of Contents

    Safety Guidelines................................34 FCC Declaration of Conformity Statement......................34 Industry Canada Notice..............................35 European Waste Electrical and Electronic Equipment (WEEE) Notice..........38 Hazardous Substances..............................39 NCC Statements.................................39 Declaration of Conformity in Languages of the European Community...........40 ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 4: Preface

    Italics are also used when referring to publication titles. Platform-Dependent Conventions Unless otherwise noted, all information applies to all platforms supported by ExtremeXOS software, which are the following: • ® ExtremeSwitching switches • Summit ® switches • SummitStack ™ ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 5: Providing Feedback To Us

    Network load at the time of trouble (if known) • The device history (for example, if you have returned the device before, or if this is a recurring problem) • Any related RMA (Return Material Authorization) numbers ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 6: Extreme Networks Documentation

    Archived Documentation (for earlier www.extremenetworks.com/support/documentation-archives/ versions and legacy products) Release Notes www.extremenetworks.com/support/release-notes Open Source Declarations Some software files have been licensed under certain open source licenses. More information is available at: www.extremenetworks.com/support/policies/open-source-declaration/. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 7: Chapter 1: Overview

    AP7662- Five external antennas (four single band antennas and one BLE antenna) • Temperature: -40 to +70°C without solar radiation -40 to +60°C with solar radiation • Enclosure: Cast Aluminum base and Top ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 8 Overview Figure 1: Top and Side Views of AP7662i IoT/BLE Radio Radio - 2.4 GHz Radio - 5 GHz Status GE1 (PoE IN) Console/Reset Vent Figure 2: Top and Side Views of AP7662 ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 9: Led Indicators

    Indicates IoT application is running 2.4GHz Radio LED Green Indicates radio is enabled 5 GHz Radio LED Amber Indicates radio is enabled Status LED Green Indicates AP is working normally Amber Indicates system failure ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 10: Chapter 2: Hardware Mounting And Installation

    The pairing of the remaining wires is not important, but 1:2 and 7:8 is commonly used. Verifying the Box Contents Verify the contents of the box and ensure that the following items are available: ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 11: Positioning The Ap For Installation

    The AP7662i/AP7662 does not come with any mounting bracket. Hence, they need to be purchased separately. Refer the table below for information on mounting brackets used with the access point and it's specifications. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 12 1-axis tilt is not required, attach the pole part of the bracket to the access point. If 1-axis tilt is required, attach the pole part of the KT-147407-01 bracket on top of the second wall part. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 13: Mounting The Ap7662I/Ap7662 To A Wall

    For other materials, use the appropriate drill for the screws being used. 3 For masonry installations, drill at least 1/8” (3mm) past the depth of the screw, or bolt, being used, and place four anchor assemblies into the holes. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 14 Use 4 M4 screw assemblies to attach the AP to the “H” bracket on the side that does not have the PEM stand-offs. b Tighten the four screws to a torque of 13.0-13.5 in-lbs. 5 Secure the anchors to the wall, then secure the bracket to the anchors. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 15 Hardware Mounting and Installation 6 If using #10 screws, tighten them to a torque of 25 in-lbs. If using ¼” screws, tighten them to 45 in- lbs. Figure 4: AP7662i Wall Mount H Bracket ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 16: Mounting The Ap7662I/Ap7662 To A Pole

    Cable Clamp Size <= 2.5" (63.5mm) Use small cable clamp 5" - 7" (178mm) Use large cable clamp Other Provide your own stainless steel cable clamp. The band must be ½" (12.7mm) wide ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 17 3 Attach the cable clamp to the pole bracket. Open the cable clamp by turning a flat bladed screwdriver counterclockwise. Then, insert the non-clamp end into the pole bracket through the holes. Note It is easier to install both clamps before attaching to the pole. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 18: Mounting The Ap7662I/Ap7662 Using Extension Arm

    AP orientation will be upright before you tighten the brackets screws. Torque the screws to 12 in-lbs. Important The wall must be strong enough to support the AP during inclement weather. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 19: Mounting The Ap Using The Kt-147407-01 Bracket To A Flat Surface

    3 Insert cable clamps that are ½" wide stainless steel through the long slots on the side of the pole bracket. 4 Locate the AP and bracket on the pole, insert the ends of the cable clamps, and tighten them to a torque of 11 in-lbs. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 20: Mounting The Ap Using The Kt-150173-01 Extension On The Kt-147407-01 Bracket

    This bracket can use either the M4 or M6 attachment screws. The bracket has four parts: • Flat plate with thumbscrews; the AP attach assembly plate • Stiffener plate #1; used with the AP attach assembly plate ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 21 Use the vehicle attach assembly plate's long inner X slots as a template and mark the holes to attach it to the desired flat surface. Figure 8: VMM Vehicle Attach Assembly plate ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 22 3 Align the large holes and assemble both the stiffener plates inside the AP attach assembly plate. Figure 9: VMM AP Attach Assembly plate stiffener #1 and stiffener #2 ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 23 6 Align the AP attach assembly plate to the vehicle attach assembly plate and tighten using four thumbscrews. Note The AP will not be centered and some of the attachment holes in the AP attach assembly plate will be visible. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 24 Figure 11: Attaching the AP unit to the VMM bracket The AP will look like this when it is mounted on to a VMM bracket. Figure 12: AP mounted on a VMM Bracket ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 25: Installing External Antennas

    The AP7662i/AP7662 has one LAN (Ethernet) port and a Console port. Refer to Features on page 7 for the location of these ports. During administration and maintenance through the LAN or Console, the AP must still have a power connection through an Ethernet PoE cable. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 26 Install the cable gland adapter assembly onto LAN 1 or LAN 2 as follows: Insert the RJ45 cable onto the sealing nut (shown below). 2 Slide the claw and seal onto the RJ45 cable (shown below). ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 27 5 Secure the seal nut onto the main body (shown below). 6 Tighten the assembly by hand. Tighten the cap to 5 inch-pounds (shown below). Note There should still be some visible threads after you torque in the cap. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 28: Professional Installation Instructions

    Utiliser uniiquement les antennes approuvees par le fabricant. L'utilisation d'autres antennes peut conduire a un niveau de rayonnement essentiel ou non essentiel depassant les niveaux limites definis par FCC/ISED, ce qui est interdit. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 29 Avertissement: Choisir avec soin la position d'installation et s'assurer que la puissance de sortie ne depasse pas les limites en vigueur. La violation de cette regle peut conduire a de serieuses penalites federales. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 30: Chapter 3: Specif I Cations

    -40° F to 140° F/ -40° C to 60° C with Solar Load Storage Temperature -40°F to 158°F/-40°C to 70°C Operating Humidity 0%-95% (noncondensing) Electrostatic Discharge Condensing electrostatic Operating Altitude 8,000 ft. at 54 °F/12 °C ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 31 Transmit power adjustment 1dB increment BTLE radio: Operating Frequencies 802.11: 2412 to 2472 MHz, 5180 to 5825 MHz BTLE radio: 2402 to 24835 MHz in 40 2 MHz wide channels GPS radio Not available in first release ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 32: Chapter 4: Regulatory Information

    Please carefully select the installation position and make sure that the final output power does not exceed the limit set force in relevant rules. The violation of the rule could lead to serious federal penalty. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 33: Instructions D'installation Professionnelle

    Utiliser uniiquement les antennes approuvees par le fabricant. L'utilisation d'autres antennes peut conduire a un niveau de rayonnement essentiel ou non essentiel depassant les niveaux limites definis par ISED, ce qui est interdit. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 34: Safety Guidelines

    This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference • This device must accept any interference received, including interference that may cause undesired operation. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 35: Industry Canada Notice

    3 De plus, les utilisateurs devraient aussi être avisés que les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5650-5850 MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LANEL. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 36 ISED établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm pour AP7662i et 42 cm AP7662 de distance entre la source de rayonnement et votre corps. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 37 Le présent émetteur radio (IC: 4141B-AP7662E/ Model: AP7662) a été approuvé par ISED pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal. Les ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 38: European Waste Electrical And Electronic Equipment (Weee) Notice

    The symbol above indicates that separate collection of electrical and electronic equipment is required. 2 When this product has reached the end of its serviceable life, it cannot be disposed of as unsorted municipal waste. It must be collected and treated separately. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 39: Hazardous Substances

    This product complies with the requirements of Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment. NCC Statements ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 40: Declaration Of Conformity In Languages Of The European Community

    övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG. Danish Undertegnede Extreme Networks erklærer herved, at følgende udstyr Radio LAN device overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
  • Page 41 Lithuanian Extreme Networks deklaruoja, kad Radio LAN device atitinka 1999/5/EC Direktyvos esminius reikalavimus ir kitas nuostatas". Polish Niniejszym, Extreme Networks, deklaruję, że Radio LAN device spełnia wymagania zasadnicze oraz stosowne postanowienia zawarte Dyrektywie 1999/5/EC. ExtremeWireless WiNG™ AP7662i/AP7662 Access Point Installation Guide...
