VIEW THE OTHER INDOOR CHANNELS (OPTIONAL FEATURE WITH ADD ON EXTRA
SENSORS)
This console is capable to pair with a wireless 7-IN-1 sensor and up to 7 wireless indoor
sensors. If you have 2 or more Indoor sensors, you can press [ CHANNEL ] key to switch
between different wireless channels in normal mode, or press and hold [ CHANNEL ] key for 2
seconds to toggle auto-cycle mode to display the connected channels at 4 seconds interval.
During auto-cycle mode, the
display. Press [ CHANNEL ] key to stop auto cycle and display the current channel.

TREND INDICATOR

The trend indicator shows the trends of changes in the
forthcoming few minutes. The icon will appear in temperature,
humidity, index and baro section.

WIND

WIND SPEED AND DIRECTION SECTION OVERVIEW
Wind direction
Wind speed
level indicator
TO SET THE WIND SPEED UNIT AND DIRECTION DISPLAY FORMAT
1. In normal mode, press and hold [ WIND ] key for 2 seconds to enter into wind speed unit
mode and the unit will flash. Press [
sequence: m/s
2. Press [ WIND ] key again to return to normal mode.
TO SELECT THE WIND DISPLAY MODE
In normal mode, press [ WIND ] key to switch between BEAUFORT scale, AVERAGE and
GUST wind speed.
BEAUFORT SCALE TABLE
The Beaufort scale is an international scale of wind velocities ranging from 0 (calm) to 12
(Hurricane force).
Beaufort Scale
0
Calm
1
Light air
icon will show on the indoor channel section of the console's
km/h
knots
Description
Wind Speed
0.3 ~ 1.5 m/s
] or [
] key to change the wind speed unit in this
mph
< 1 km/h
< 1 mph
Calm. Smoke rises vertically.
< 1 knots
< 0.3 m/s
1.1 ~ 5km/h
1 ~ 3 mph
Smoke drift indicates wind direction.
Leaves and wind vanes are stationary.
1 ~ 3 knots
16
Rising
Steady
Real time wind
direction indicator
Past wind
directions indicator
of last 5 minutes
Average / gust
wind speed
Land Condition
Falling
