GFW MORGAN Assembly Instruction

COMPONENTS
01 2 X HEAD POST 05
02 2 X FOOT POST
06
03 1 X HEAD GUIDE
04 1 X FOOT GUIDE
FITTINGS
A
SCREW M6 X 15MM 8 PCS
C
SCREW M6 X 60MM 12 PCS
E
4 PCS
JCN NUT M6 X 20MM
1 X CENTER RAIL
14 X CROSS BAR
07
2 X SUPPORT LEG
08
4 X LONG TUBE
2 X RAIL
09
B
SCREW M6 X 35MM 10 PCS
D
2 PCS
WASHER M6
F
2 PCS
M4 ALLEN KEY
MORGAN SINGLE BED
Simple Assembly Instruction - Please keep for reference
IMPORTANT
1 ) Read these instruction carefully and
familiarise yourself with the procedure
before assembling the unit.
2 ) Check that you have all the component
parts following the list on the back
cover and familiarise yourself with
each part before proceeding.
30 - 45 MIN
TWO PEOPLE ARE NEEDED TO ASSEMBLY THIS BED.
3 ) Take all the fitting out of the plastic bag
and separate them into their groups.
4 ) Ensure you have enough space to layout
all the parts before assembly.
5 ) To avoid scratching it is recommended
that you assemble the unit on a soft
level surface.
NOT SUPPLIED
