NuAire IAQ-V125 Installation Manual

1.0 SAFETY INFORMATION
•
Precautions must be taken to avoid the back-flow of gases into the room from the open flue of
gas or other fuel-burning appliances.
•
This appliance should not be used by children or persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge, unless they have been given supervision
or instruction concerning the safe use of the appliance by a person responsible for their safety.
Children shall not play with the appliance. Cleaning and user maintenance shall not be carried
out by children.
•
To ensure levels of NO2 are being reduced, the carbon filters should be replaced every 2 years as
per our recommended maintenance.
•
Carbon filters/pellets are not to be ingested, ensure hands are thoroughly washed after handling.
1.1 Hazard Symbols
GENERAL WARNING
Signifies a general warning regarding hazard specified by supplementary information.
REFER TO INSTRUCTION MANUAL
Read and understand the installation and maintenance manual before installing,
operating or maintaining this product.
1.2 Important Information
This manual contains important information on the safe and
appropriate assembly, transport, commissioning, operation,
maintenance, disassembly and simple troubleshooting of the product.
While the product has been manufactured according to the accepted
rules of current technology, there is still a danger of personal injury or
damage to equipment if the following general safety instructions and
the warnings contained in these instructions are not complied with.
•Read these instructions completely and thoroughly before
working with the product.
•Keep these instructions in a location where they are accessible
to all users at all times.
•Always include the operating instructions when you pass the
product on to third parties.
1.3 Personal Protective Equipment
The following minimum PPE (Personal Protective Equipment) is
recommended when interacting with Nuaire product:
•Full Finger Gloves (Marigold PU800 or equivalent) - when
handling sheet metal components or knives. When using silicone,
Butyl rubber gloves (0.4mm) are recommended.
•Safety Glasses - when conducting any cleaning/cutting operation
or exchanging filters.
•Reusable Half Mask Respirators - when replacing filters which
have been in contact with normal room or environmental air.
Nuaire would always recommend a site specific risk assessment by a
competent person to determine if any additional PPE is required.
Nuaire |
Western Industrial Estate
IAQ-V125
125mm Ø Carbon Filtered Valve
Installation Manual
| | | nuaire.co.uk
Caerphilly CF83 1NA
2.0 INTRODUCTION
Nuaire's 125mm diameter Carbon Filtered Supply Valve has been
specifically designed to reduce the level of airborne contaminants
entering the property, in particular up to 91% of nitrogen dioxide
(NO2), thus improving indoor air quality (IAQ).
The IAQ-V125 valves incorporate a carbon filter. The valve is adjustable
for commissioning purposes, lockable and spring loaded to prevent
vibration. Replacing the carbon filter is quick and easy and leaves the
valve adjustment unaffected.
An airflow screen is provided and can be fitted to deflect the airflow
away from walls and other obstructions, such as smoke alarms.
IAQ-V125 valves should be fitted on the supply leg of the ducting and
therefore do not require insulation (Figure 2).
To aid in maintenance, the valves are easily removable and do not
require re-commissioning.
2.1 Main Features
•IAQ-V125 can remove up to 91% NO2 entering the property.
•Low profile.
•Adjustable for commissioning purposes.
•Decorative panel to cover commissioning screw.
•Spring loaded to prevent vibration.
• Valve easily removed for maintenance and does not require
re-commissioning.
•Quick and easy carbon filter replacement.
•Supplied with airflow screen to enable air to be directed away from
obstacles.
16. 03. 20. Document Number 671852
1
