Royal Mounts ROY7707B User Manual

INSTALLATION
Step 2: Install back plate covers
1. Position and attach arm with mounting hardware
G F
E
I
Step 3: Mount the VESA bracket to the TV
1. Finish assembling the TV mounting bracket
D
H
Step 4: Secure TV
1. Connect TV to mounting arm
LIMITED LIFETIME WARRANTY
This Royal product carries a LIMITED LIFETIME WARRANTY on both parts and labor. Should your mount fail to operate
properly at any time during the warranty period, Royal will repair or replace (at our option) the item barring any indication of
misuse or abuse. Freight to a Royal authorized facility is paid by the customer. Return freight is paid by Royal. Warranty
registration occurred automatically at the time your order was placed. There is no need to complete or mail in additional
paperwork. If you have any questions about the operation or installation of this product, please call our distributor, Skywalker
AV Supply at (800) 844-9555 or (636) 272-8025. Skywalker AV Supply hours of operation are from 8am to 5pm CST.
FULL-MOTION WALL MOUNT
2. Fasten the covers to the mount
2. Attach bracket to the TV using spacers if necessary
2. Tighten hardware and lock in place
