Philips CoolSkin HQ 5660 Service Manual

! !
Service Service
Information Information
Domestic Appliances and Personal Care
GENERAL
- Cool skin is a new shaving system.
The shaver features a special compartment for
cartridges containing Nivea for Men moisturising
shaving emulsion.
This emulsion is applied to the skin while shaving.
- The shaving unit can be cleaned under a running hot
tap.
The HQ156 shaving heads are made of special
stainless steel for corrosion-free cleaning with water.
- The shaver has a separate trimmer for grooming
sideburns and moustaches.
The trimmer can be flipped open to enable cleaning
of the inside.
- The charging stand of the shaver can be placed on a flat
surface or it can be attached to the wall.
The PCB inside is encased in insulating material.
For this reason the mains cord cannot be replaced if it is
damaged.
Published by Philips Domestic Appliances and Personal Care
4822 729 21977
98/09
PCS 99 514
TECHNICAL DATA
Input voltage
Motor voltage
Cell
Cell capacity
Charging indicators : duoLED red/green
Charging time
Charging current
Charging device
Comfort control
Shaving heads
Shaving emulsion
MSH Coding
8855 660 00000 HQ 5660
©
Printed in The Netherlands Copyright reserved
Rechargeable shaver
HQ 5660/A
CoolSkin
: 100-240 V, 50/60Hz
: 2.4 V
: 2X 4/5AA NiMH
: approx. 1000 mAH
: approx. 1 hour
: 1000/100/25 mA time-dependent
: Switched Mode Power Supply in
stand
in : 100-240
out : 12-17 V
: fixed setting
contour following
: HQ156 - 4822 690 10152
: HQ150 - 4822 390 10156 W-EU
Subject to modification
