R35
Intelligent Robot Vacuum Cleaner
Aspirateur Robot Intelligent
Thank you for choosing PUPPYOO vacuum cleaner.
Please read the user guide carefully before use.
Merci d'avoir choisi l'aspirateur PUPPYOO.
Veuillez lire attentivement le mode d'emploi avant de l'utiliser.

Advertisement

loading
Need help?

Need help?

Do you have a question about the R35 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for PUPPYOO R35

  • Page 1 Intelligent Robot Vacuum Cleaner Aspirateur Robot Intelligent Thank you for choosing PUPPYOO vacuum cleaner. Please read the user guide carefully before use. Merci d’avoir choisi l’aspirateur PUPPYOO. Veuillez lire attentivement le mode d’emploi avant de l’utiliser.
  • Page 2 Thank you for you choosing R35 series robot vacuum cleaner, should you have any question on this product, please contact us by phone Merci d’avoir choisi l’aspirateur robot série R35 si vous avez des questions sur ce produit, veuillez nous contacter par téléphone...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING (THISAPPLIANCE), Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. WARNING To reduce the risk of fire, electric shock, or injury: 1.
  • Page 4 20. Do not expose a battery pack or appliance to fire or excessive temperature. Exposure to fire or temperature above 130°C may cause explosion. 21. Follow all charging instructions and do not charge the battery pack or appliance outside of the temperature range specified in the instructions. Charging improperly or at temperatures outside of the specified range may damage the battery and increase the risk of fire.
  • Page 5 IMPORTANTES MESURES DE SÉCURITÉ L’utilisation d’un appareil électrique demande certaines précautions: LIRE TOUTES LES INSTRUCTIONS AVANT DE FAIRE FONCTIONNER (CETAPPAREIL), Le non-respect des mises en garde et des instructions peut causer des chocs électriques, des incendies et/ou des blessures graves. AVERTISSEMENT.
  • Page 6 17. Lorsque l’appareil n’est pas utilisé, tenir la batterie loin d’objets métalliques comme des trombones, des pièces de monnaie, des clés, des clous, des vis ou autres petits objets qui pourraient établir une liaison entre les bornes. Un courtcircuit des bornes des batteries peut causer des brûlures ou un incendie.
  • Page 7 FCC/IC COMPLIANCE / TM / WARRANTY To satisfy FCC&IC RF exposure requirements, a separation distance of 20cm or more should be maintained between the antenna of this device and persons during device operation. To ensure compliance, operations at closer than this distance is not recommended. Les antennes installées doivent être situées de facon à...
  • Page 8 Contents 1. Safety Instruction 1.1 Notice for use 1.2 Matters need attention 1.3 Battery 1.4 Usage range 2. Product 2.1 Main body and components 2.2 Parts name 3. Product assembly 3.1 Adapter and charging stand combination 3.2 Installing the charging stand 3.3 Installing a dust box or water tank 3.4 Using the wet drag function 4.
  • Page 9 Contenu 1. Instruction de sécurité 1.1 Avis d'utilisation 1.2 Les questions ont besoin d'attention 1.3 Batterie 1.4 Plage d'utilisation 2. Produit 2.1 Corps principal et composants 2.2 Nom des pièces 3. Assemblage du produit 3.1 Combinaison de l'adaptateur et du support de charge 3.2 Installation du support de charge 3.3 Installation d'une boîte à...
  • Page 10 WARNING Do not use to absorb sharp Do not use in a wet or objects, such as glass sheets, flammable, explosive or nails, etc., to avoid damage corrosive environment. to the product. Unplug the power cord for When the product is working, a long time without using removing the charging stand the charging stand.
  • Page 11 1. Safety Instruction 1.1 Notice for use Before use, please read the safety precautions below carefully. * Please ready all the instructions before using this appliance. * In order to ensure proper operation, please keep this manual appropriately.  * If you want to give this appliance to a third party, please include this manual along with the appliance.
  • Page 12 1.3 Battery 1) This product is limited to use the battery equipped by the manufacture. 2) Please remove the battery before dispose the appliance. 3) Please contact with our after sale service if you want to replace the battery. Do not use any other charger to recharge the battery pack.
  • Page 13 2. Product 2.1 Main body and components Charge Station x1 Adaptor x1 Side brush x2 Main Unit screw driver x1 Cleaning Brushx1 User Certificate Manual Approval Dust cup x1 Mop x1 Pallet x1 Warm tip Dust cup, filter screen net, and battery are already installed in the main body.
  • Page 14 2.2 Parts name Upper flip Main body Transparent button window Front Anti-collision Anti- drop sensors*3 Front wheel Charging slice*2 Cross country walking wheel Floating brush Floating brush cover buckle *2 Water tank buckle *2 Wet water seepage hole Battery cover WIFI indicator Retour and Start/pause...
  • Page 15 Power indicator Signal transmitting area Charging contactor Dust container Filter bracket HEPA filter net 3 Product installation 3.1 Adapter and charging stand 1. Open the bottom plate of the charging stand. 2. Insert the adapter cylindrical plug into the DC connector inside the charging stand.
  • Page 16 2. Before use, be sure to remove the protective strip on the device's bumper to ensure the normal use of the device. 3. Power on: Push the On/Key to “On” and press the Start/Pause button. 4. Use Method 1: Press the button on the top cover Wall sensor of the main unit to start, pause and recharge.
  • Page 17 3.4 Use the wet drag function Note Do not use the mop function on the carpet 1.First fill the water tank to 90% and close the water inlet. (Note: If the metal contact on one side of the water tank is wet, please dry it and put it in the dust box.) 2.
  • Page 18 4. Using product 4.1 Buttons and indicators Start/pause button WIFI indicator Retour and recharge Button Button description Retour and recharge button 1. When the machine is in standby state, the power light will display “blue”, press the recharge button, and the machine enters the recharge mode.
  • Page 19 4.2 Use of main body 1. Side brush assembly 2. Turn on Install the side brush and use a screwdriver to 1) Before use, be sure to remove the protective load the side brush into the sweep.Screw the strip on the device's bumper to ensure that the corresponding position on the bottom of the device is in normal use.
  • Page 20 After downloading, follow the normal procedure to install the app to find the corresponding indicator icon in the application. Use environment After the mobile phone opens the "PUPPYOO R3X" app, after registering and logging in, follow the APP prompts to set up the sweeper and network settings.
  • Page 21 5.1 Register and login 1. The above picture shows the 2. Enter the mobile number in 3. You can complete the interface after the APP is the “Registration” screen shown registration by entering the opened. On this interface, you above and set a login six-digit verification code can enter the registered phone password.
  • Page 22 5.2 Add device There are three ways to add a 1. Click on “Add Device” to scan device: this QR code or manually enter 1) Scanning device QR code the device number: r-35- for image device addition. 2) Identify from photos 3) Manual input 2.
  • Page 23 6. After waiting for the robot to 5. Open the cover of the machine, push the power button to “ON”, the be bound and added start button “ ” lights up, Enter the successfully, click the robot icon standby state. After long press the to enter the control page.
  • Page 24 5.3 Operation page · On the main control page, Fan mode: Direction key: there are three cleaning Select “fan mode”, 3 position Select “Direction key” to enter modes: “Planning Cleaning”, suction can be adjusted. the virtual remote control “Spot Cleaning” and “Edge option, long press the direction Cleaning”...
  • Page 25 5.4 More function Click the “ ” icon in the upper right corner of the operation page to enter the setting page, and click to enter the corresponding function. 1. Reservation. 2. Sharing devices: Select Select "Reservation" to set and “Share Device”...
  • Page 26 6. Product maintenance 6.1 Battery storage Tips Please clean and maintain the sweeping robot regularly according to the usage. Do not use the sweeper for a long time, please fully charge the battery, then remove the battery and store it in a cool, dry place.Keep the bottom of the sweeper dry.
  • Page 27 6.4 Clean main brush 1. As showed in the picture,push lock bar and pull up;Grad the main brush and pull up; 2. Take out rubber bar and main brush. 3. Use a cleaning brush to clean the middle, middle and middle sweeps, and sweep the middle.Hair and other wraps on the brush should be cleaned regularly.
  • Page 28 6.5 Clean side brush Remove the side brush as shown, and use a cleaning brush to clean the side brush and the wrap around the card slot. 6.6 Clean wheels As shown in the figure, Clean the wheels in front and on both sides of the machine with the cleaning brush regularly.
  • Page 29 7. Trouble shooting Trouble indicator: Red indicator flash on high freqnency, please follow voice reminder and check problems Trouble Reason Solution Dust container problem Dust container taken out Set dust conttainer into main body Off-ground problem Robot is lifted up or halt Put robot back to ground Ground-examine prolem Anti-drop sensors blocked or...
  • Page 30 8. Parameters Main body Accessories Operating voltage Adapter DC14.4V Rated power Output voltage DC24V Battery Li-ion battery Output current Battery capacity 2500mAh Charging station Charging time 3-5 hours Charging station model CD024 Working time 120 mins Input voltage Working temperature 0℃-45℃...
  • Page 31 ATTENTION Ne pas utiliser pour Ne pas utiliser dans un absorber des objets pointus, environnement humide ou tels que des feuilles de inflammable, explosif ou verre, des ongles, etc., afin corrosif. d’éviter d’endommager le produit. Lorsque le produit Débranchez le cordon fonctionne, le retrait du d'alimentation pendant une support de charge empêche...
  • Page 32 1. Instruction de sécurité 1.1 Avis d'utilisation Avant utilisation, veuillez lire attentivement les précautions de sécurité ci-dessous. * Veuillez lire toutes les instructions avant d'utiliser cet appareil. * Afin de garantir un fonctionnement correct, veuillez conserver ce manuel correctement. * Si vous souhaitez donner cet appareil à un tiers, veuillez inclure ce manuel avec l'appareil. * Toute opération non conforme à...
  • Page 33 1.3 Batterie 1) Ce produit est limité à l’utilisation de la batterie fournie par le fabricant. 2) Veuillez retirer la batterie avant de jeter l'appareil. 3) Veuillez contacter notre service après-vente si vous souhaitez remplacer la batterie. N'utilisez aucun autre chargeur pour recharger la batterie. 4) Si la batterie présente une fuite, ne laissez pas le liquide pénétrer dans la peau ou les vêtements, nettoyez-le immédiatement avec un chiffon sec et remettez-le dans la corbeille à...
  • Page 34 2. Produit 2.1 Corps principal et composants Brosse latérale x2 Station de charge x1 Adaptateur x1 Partie principale Tournevis x1 Brosse de nettoyage x1 Coupe poussière x1 Balai x1 Manuel de l'utilisateur x1 Palette x1 Certificat d'approbation x1 Pointe chaude Le godet à...
