Summary of Contents for Versa-Matic E5
- Page 1 1/2" Elima-Matic Bolted Plastic/Metallic Pumps with Metallic Center Sections E5 Plastic Pumps • Polypropylene • Kynar • Acetal E5 Metallic Pumps • Aluminum • Stainless Steel • Hastelloy C...
-
Page 2: Warnings, Cautions & Notices
WARNINGS, CAUTIONS & NOTICES Please read all cautions, warnings and notes this manual for reference. Failure to comply with completely before installation and start-up. the recommendations stated in this manual may It is the responsibility of the purchaser to retain damage the pump and void the factory warranty. - Page 3 ® VERSA-MATIC MODEL IDENTIFICATION CODES X X X X X X X X X X - X X X Options (if applicable) Revision Level Construction Design Valve Seat Material/Valve Seat O-ring Material Valve Ball Material Diaphragm Series Diaphragm Material Non-Wetted Parts...
-
Page 4: Specifications And Performance
SPECIFICATIONS AND PERFORMANCE Versa-Matic Model Displacement Per Stroke, 0.03 Gal. (0.11 L) E5 1/2" Bolted Plastic Pump AIR CONSUMPTION IN SCFM AIR PRESSURE IN PSI Flow Rate Adjustable to ..0-14 gpm (56 lpm) - Page 5 SPECIFICATIONS AND PERFORMANCE Versa-Matic Model Displacement Per Stroke, 0.03 Gal. (0.11 L) E5 1/2" Bolted Metallic Pump AIR CONSUMPTION IN SCFM AIR PRESSURE IN PSI Flow Rate Adjustable to ..0-14 gpm (56 lpm)
-
Page 6: Installation
INSTALLATION, OPERATION & MAINTENANCE Installation Pump Operation The pump should be mounted in a vertical position. The pump is powered by compressed air. In permanent installations, the pump should be Compressed air is directed to the pump air chamber attached to plant piping using a flexible coupling by the main air valve. -
Page 7: Troubleshooting
TROUBLESHOOTING Symptom Potential Cause(s) Recommendation(s) Pump cycles once 1 Incorrect pilot o-ring placement 1 Reinstall pilot o-rings in correct positions 2 Inner diaphragm plate installed backwards 2 Reinstall inner diaphragm plate correctly 3 Deadhead (system pressure meets or exceeds 3 Check system for pressure ratio to pump air supply pressure) 4 Install gaskets with holes properly aligned 4 Air valve or center block gaskets installed incorrectly... - Page 8 E5 1/2" Bolted Plastic Parts List AIR VALVE ASSEMBLY Item Description Qty. Standard: Polypropylene Option 1: Aluminum Air Valve Assembly (Includes items 1-10) E500 E500 Valve Body E500A E500A Valve Spool Assembly (Includes U-Cups) E500B ASY E500B ASY Valve Spool U-Cup...
-
Page 9: Exploded Views
EXPLODED VIEWS Exploded View shows Rugged Diaphragm Teflon Diaphragms Grounding Strap Versa-Matic ® E5 1/2" Bolted Plastic OM... - Page 10 E5 1/2" Bolted Metallic Parts List AIR VALVE ASSEMBLY Option 1: Aluminum Item Description Qty. Standard: Polypropylene Air Valve Assembly (Includes items 1-10) E500 E500 Valve Body E500A E500A Valve Spool Assembly (Includes U-Cups) E500B ASY E500B ASY Valve Spool U-Cup...
- Page 11 EXPLODED VIEWS Exploded View shows Rugged Diaphragm Teflon Diaphragms Versa-Matic ® E5 1/2" Bolted Metallic OM...
-
Page 12: Materials, Temperature Limits & Compatibility
PVDF Stainless Steel ■ ■ ■ E6 (1/4") ● ● E8 (3/8") ● ● ● ●▲ ●▲ ● E5 (1/2") ● E7 (3/4") ● ● ●▲ ●▲ ● E1 (1") ■ ■ ●■ ● ● ●■ E4 (1-1/4" – 1-1/2") ●■... - Page 13 ® PUMPER PARTS The Only Difference is the Price. A division of Versa-Matic Pump Company, Pumper The Pumper Parts Promise Parts is your single source for Air-Operated Double All Pumper Parts products are: Diaphragm (AODD) pump • Engineered to perform parts.
- Page 14 SHALL HAVE NO LIABILITY OR OBLIGATION WITH does not apply to or include: RESPECT TO ANY PRODUCT. • Any product that is not sold by Versa-Matic as new UNDER NO CIRCUMSTANCES SHALL VERSA-MATIC • Any accessory or other product that does not bear...
-
Page 15: Declaration Of Conformity
Dir produkt voldoet aan de volgende EG-richtlijnen: Denna produkt överensstämmer med följande EU direktiv: Versa-Matic, Inc., erklærer herved som fabrikant, at ovennævnte produkt er i overensstemmelse med bestemmelserne i Direkktive: Tämä tuote täyttää seuraavien EC Direktiivien vaatimukstet: Dette produkt oppfyller kravene til følgende EC Direktiver: Este produto está... - Page 16 Geolast® is a registered trademark of AES. Ultra-Matic™, Versa-Dome®, Versa-Matic®, Versa-Tuff® and Versa-Rugged VR™ are registered tradenames and trademarks of IDEX Corporation. VERSA-MATIC ® PUMP COMPANY A Unit of IDEX Corporation 6017 Enterprise Drive Export, PA 15632-8969 (724) 327-7867 Fax: (724) 327-4300 VME5-BPBMOM-1008 www.versamatic.com...
