Summary of Contents for Zeiss Supreme Prime
- Page 1 ZEISS Supreme Prime Mount Change Instructions...
-
Page 2: Table Of Contents
Table of Contents Introduction Explanation of Symbols Overview Delivery Contents of a ZEISS Supreme Prime Technical Data Changing the Mount of a ZEISS Supreme Prime Detaching a Mount Attaching a Mount Adjusting a ZEISS Supreme Prime to Your Digital Camera... -
Page 3: Introduction
Introduction In this manual you learn how to change the mount of a ZEISS Supreme Prime and how to match it to a digital camera. In order to explain the procedure, this manual uses a ZEISS Supreme Prime lens, which is scaled in feet with PL mount. -
Page 4: Delivery Contents Of A Zeiss Supreme Prime
Close focus distance is measured from the image plane Front to PL mount flange The specified weight refers to the ZEISS Supreme Prime standard lenses. Horizontal angle of view for a full-frame camera (aspect ratio 1:1.5, dimensions 36 mm x 24 mm / 1.42“ x 0.94“) -
Page 5: Changing The Mount Of A Zeiss Supreme Prime
Changing the Mount of a ZEISS Supreme Prime Lens In this chapter you learn how to change the mount of a ZEISS Supreme Prime. The procedure consists of two parts which are both mandatory to successfully change a mount. You learn how to detach the currently attached mount and how to attach a different mount. - Page 6 Ensure that your working space is flat and leveled, in order to prevent the lens from tilting and falling over. Ensure that the environment is clean and free from dust so that no dust particles enter the ZEISS Supreme Prime.
- Page 7 1. Place your ZEISS Supreme Prime on a flat surface with the mount facing up and the serial number facing away from you. The serial number is located at the side of the lens foot. The serial number varies. 2. Remove the rear lens cap.
- Page 8 4 . Carefully detach the mount from your ZEISS Supreme Prime. If you are changing from a PL mount, you can directly see the shims. When detaching the mount for the first time, do not remove the shims. Never remove the small screw in the groove of the lens.
-
Page 9: Attaching A Mount
1. Carefully place the adapter ring, which came with your ZEISS Interchangeable Mount Set for the ZEISS Supreme Prime. Make sure the small screw in the groove of the ZEISS Supreme Prime sinks into groove of the adapter ring and... - Page 10 3. Place the mount on your ZEISS Supreme Prime: PL mount: Place the PL mount on the ZEISS Supreme Prime in such a way that the recess of the mount lays on top of the electrical interface. The groove on the other side of the PL mount should then also lay on top of the small...
- Page 11 3.II LPL mount: Place the LPL mount on the ZEISS Supreme Prime in such a way that the recess of the mount lays on top of the electrical interface. The groove on the other side of the LPL mount should then also lay on top of the small...
-
Page 12: Adjusting A Zeiss
4. With the T6 torx wrench tighten the torx screws using a torque of 0.4 N You have now successfully changed the mount of a ZEISS Supreme Prime. In this chapter you learned how to detach the mount of your ZEISS Supreme Prime and attach a new mount to your ZEISS Supreme Prime To make sure your ZEISS Supreme Prime works properly, also complete the subsequent procedure: Adjusting a ZEISS CP.3... -
Page 13: Testing The Sharpness
The use of tools offered by ZEISS is highly recommended. You can purchase these tools directly from ZEISS or your trusted ZEISS Dealer. See Mount Change Accessories ZEISS Supreme Prime lens are clean. Testing the Sharpness 1. Fasten the siemens star test chart on a wall. - Page 14 6. Set the aperture of the Supreme Prime to full speed by rotating the aperture ring. The aperture setting must not be changed during the adjustment process. 7. Activate the live view of your camera. 8. Select the maximum magnification of the live view.
-
Page 15: Correcting The Flange Focal Distance
Example: Using a Supreme Prime 35mm/T1.5 lens with an EF mount, scaled in feet and a test chart at a test distance of 4 ft, an actual distance of 4 ft 1´ is measured. Due to the table on page 18, you add a silver shim 0.013mm to the total thickness of the shims. - Page 16 If you achieve the maximum sharpness at the testing distance proposed in the tables, you successfully tested your Compact Prime Supreme Prime. No further steps are required. In this chapter you learned how to adjust a Compact Prime Supreme Prime...
-
Page 17: Appendix
Appendix Color Code of the Shims Shimming Table Minus sign: Enlarge the flange focal distance. Remove Shims Plus sign: Reduce the flange focal distance. Add Shims Light Blue Meter distance scale Feet distance scale Distance to test chart [mm] 3000 Distance to test chart [ft] Object distance at... - Page 18 2970 -0,04 9ft 10 1/2’ -0,05 2980 -0,02 9ft 11’ -0,03 2990 -0,01 9ft 11 1/2’ -0,02 3000 0,00 10ft 0’ 0,00 3010 +0,01 10ft 1/2’ +0,02 3020 +0,02 10ft 1 ‘ +0,03 3030 +0,04 10ft 1 1/2’ +0,05 3040 +0,05 10ft 2’...
-
Page 19: Mount Change Accessories
Mount Change Accessories Accessories ZEISS Identification Number Front Lens Cap Supreme Prime 4047865905114 Rear Lens Cap - PL 4047865900577 IMS LPL - XD eXtended Data – T1.5/135; T1.8/150 000000-2329-934 IMS LPL - XD eXtended Data – T1.5/21 000000-2330-031 IMS LPL - XD eXtended Data – T1.5/25; T1.5/29; T1.5/35; T1.5/50; T1.5/85; T1.5/100 000000-2271-441 IMS LPL - XD eXtended Data –... -
Page 20: Glossary
Glossary Flange focal distance flange-to-film distance, flange focal depth, flange back distance, flange focal length Shim washer Index mark aperture indicator, aperture line, aperture mark, aperture index Flat-blade screwdriver slotted screwdriver, flathead screwdriver... - Page 21 Carl Zeiss AG Consumer Products Carl-Zeiss-Straße 22 73446 Oberkochen Germany www.zeiss.com/cine...
