1. Introduction & Characteristics
Dispose of this product in accordance with Local and National Disposal Regulations.
Thank you for buying the KNS3 ! Read this manual carefully before bringing the device into use.
• Easy to build, no glue or soldering required.
• Dislodge pre-cut pieces when you need them, not before. Sand any jagged edges before use (sandpaper included).
• The kit is powered by 2 AA-batteries (not included).
The kits of the KNS-series are supplied with prepunched boards, a gearbox, gears, shafts, a switch, a motor, a
battery holder and all necessary parts.
2. Parts List
Part n° Quant.
1
1
2
1
3
1
4
1
5
1
6
1
7
1
8
1
9
1
10
2
11
2
12
2
13
8
14
6
15
2
KNS3
KNS3 – ROBOMECH
Description
gearbox
motor 3Vdc
pinion gear 8T
gear 40T/0T (white)
gear 40T/10T (red)
gear 40T/10T (green)
face gear 36T/10T (white)
metal shaft (3 x 52mm)
metal shaft (2 x 40mm)
nylon pad
nylon post (H : 3mm)
nylon connector
nylon pad Ø8mm
washer
nut M2
Referencia Electrónica Embajadores:
Part n° Quant.
16
18
17
2
18
2
19
2
20
2
21
2
22
1
23
1
24
1
25
1
26
1
27
2
28
2
29
2
30
1
Fig.1
- 1 -
KV6A003
Description
self-tapping screw (2 x 4mm)
self-tapping screw (3 x 16mm)
screw
rivet
nylon cap
LED with wires
wire with terminal (yellow)
wire with terminal (green)
battery holder
slide switch with wire
PVC tube (small)
PVC tube (large)
metal foot (U-shaped)
fixing plate (large)
fixing plate (small)
