- Page 1 Owner / Operator Installation Manual Our installation manual will walk you through the process step by step www.TVformytruck.com...
-
Page 2: Table Of Contents
(Sold with Epic and Epic Premium Package) Connecting the DIRECTV Non-DVR Receiver..........16 (Sold with Basic Package) Configuring and Activating the DIRECTV Receiver……......17-21 Installing the Local Area Antenna.…………..........22 (Winegard Rayzar Amplified Antenna if purchased separately) You can also view corresponding step by step videos on our website at: www.TVformytruck.com/installation... -
Page 3: Contact Epicvue
Do not paint the dome cover. Painting the dome cover may cause signal degradation and will void your warranty. Professional Installation recommended. If the unit is not installed properly, EpicVue’s warranty may be voided. Before Installation When choosing a location to install the antenna mount, keep in mind that the satellite antenna requires a clear line of site of the southern sky. -
Page 4: Tools Required
TOOLS REQUIRED 2. 7/16” 2. 1/4” 1. 3/8” 1. 3/8” 1. 1/2” 2. 3/4” 1/2” 3/8” • Drill – for drilling holes in the back of the sleeper 1. 3/8” drill bit 2. 1/4” drill bit • Riv Nut Tool – used to secure riv nuts into holes drilled in back of sleeper. *Can be purchased separately. -
Page 5: Receiving Your Order
Receiving Your Order Shortly before receiving your order, EpicVue will send an email with the shipping information and tracking link. When the shipment arrives, please be sure all the items noted were received and there is no apparent damage. If anything appear to be damaged, please take pictures and notify EpicVue immediately by calling 1-866-335-9719. - Page 6 DIRECTV Receiver Box • DIRECTV Receiver • DIRECTV Access Card • Power cord Rear Mount Box • Rear Mount • Sealed pack containing • 8 Riv-nuts • 8 bolts (1/4 - 20 long) • 4 bolts with Lock Nuts (5/16 size) •...
-
Page 7: Dome Rear Mount Installation
Dome Rear Mount Installation This mount is placed preferably on the driver’s side back of the cab. The driver’s side is preferable in order to minimize the dome being impacted by tree branches. If the truck is hauling reefers, then it is important to mount the bracket as close as possible to one side of the sleeper (again preferably the driver’s side) and not in the middle of the truck. - Page 8 When at least six of the pilot holes are drilled, take out the 1/4”-20 bolts, set the fixed mount base aside. Using the 3/8” drill bit, drill out all six previously drilled pilot holes. Using the impact gun set at 1100 to 1300 inch- pounds and the 3/8 Hex bit with the Riv-nut tool, twist one of the Riv-nuts on the end of the Riv-nut tool mandrel.
- Page 9 Now it’s time to put the EpicVue satellite dome on the bracket. There are two sets of mounting holes on the Top Pivot Plate. Use the set of holes that allows you to get the dome as close to the truck as possible.
- Page 10 Key Points of the Dome Rear Mount Install • Make sure that you have all your items needed before beginning. • Regulations for DOT require the height of no more than 13’6”, so install the top of the bracket at 12’4”will set the top of the dome just under the DOT height requirement.
-
Page 11: Connecting The Coaxial Cables
Connect the other coax line without writing to the secondary port of the dome. *If installing the single coax included with the EpicVue basic package connect it to the main Coax Behind & Through port. Bracket Feed this coax across the sleeper and down through the wind-fairing brackets. - Page 12 Drill a 1-1/8” hole using a step bit or a hole saw. Next run the cables through the hole, making sure they are pulled tight (without kinking the cable). Add flex tubing around the cables to prevent them from rubbing and shorting out. Use a zip tie or two underneath the sleeper to prevent the coax from hanging down and catching on something.
- Page 13 Epicvue AC power box labeled Antenna. Take the small jumper coax provided in the kit and connect it to the port on the left of the AC power box labeled Receiver.
-
Page 14: Connecting The Directv Dvr Receiver
Do not call the number on your TV screen. This is a general DIRECTV number. EpicVue has set-up a dedicated 24 hours a day, 7 days a week driver support number (1-866- 900-4434). Please call this number anytime you need help with your EpicVue system. - Page 15 Run the HDMI cord from the TV HDMI slot into the HDMI slot on the DIRECTV receiver. Plug both the DIRECTV and TV power cords into the power-strip along with the AC Power box. Plug the power-strip into the inverter (or APU) that is installed in the truck.
-
Page 16: Connecting The Directv Non-Dvr Receiver
Connect the coax to the port on the right hand side of the Epicvue AC power box labeled Antenna. Take the small jumper coax provided in the kit and connect it to the port on the left of the AC power box labeled Receiver. -
Page 17: Configuring And Activating The Directv Receiver
Now power on the power-strip and push the button on the front of the Epicvue AC Power Box. If the TV is brand new out of the box, follow the prompts and go through the standard set up. - Page 18 The screen for the DIRECTV receiver should now be displayed. The first screen will allow a language to be selected. Using the arrow keys on the remote control move to the language you prefer and press select. This is the critical part of the receiver set up. On the dish type, select 01: Round Dish 18”.
- Page 19 “refresh the receiver”, provide them with the access card number located on the screen. DIRECTV will then send a hit to the receiver. After the hit comes through, the screen will change and will go to a configuration page. Select Continue regardless of what is shown on this screen.
- Page 20 705, which NFL Sunday Ticket. *If any screen is blank, or in the case of NFL Sunday Ticket, the DIRECTV logo is not showing, then please inform the DIRECTV agent. If they are not able to resolve this issue, please call EpicVue at 1-866-335-9719.
- Page 21 Verifying the Driver Quick Tip guide is in the cab will answer most of the questions a driver will have with their new system. Configuring and Activating the DIRECTV Receiver www. T Vformytruck.com/installation...
-
Page 22: Installing The Local Area Antenna
(Winegard Rayzar Amplified Antenna if Purchased Separately) EpicVue is also included in an off-air antenna with every system. It’s a Winegard Rayzar amplified antenna, one of the best on the market. Install this antenna as it is by far a higher- quality antenna than what comes on the truck.
