  • Page 2 Hinweis: Andrew lehnt jede Haftung Oder Verantwortung fur Schaden ab, die aufgrund unsachgemaBer Installation, Uberprufung, Wartung Oder Demontage auftreten. Atencao: A Andrew abdica do direito de toda responsabilidade pelos resultados de praticas inadequadas e sem seguranca de instalacao, inspecao, manutengao ou remocao.

  • Page 3: Section 1 Contents & Introduction

    INSTALLATION SECTION 1 7834998 INSTRUCTIONS CONTENTS & INTRODUCTION Page 3 of 26 INTRODUCTION This instruction describes how to assemble and adjust a SHP(X)4 antenna. The antenna can be mounted with the mount offset to the left or to the right. Offset left is described in this bulletin, however the images showing offset right installation are shown at the end of this document.

  • Page 4: Installation Instructions

    INSTALLATION SECTION 2 7834998 INSTRUCTIONS SAFETY INSTRUCTIONS Page 4 of 26...
  • Page 5 INSTALLATION SECTION 2 7834998 INSTRUCTIONS SAFETY INSTRUCTIONS Page 5 of 26...

  • Page 6: Section 3 Equipment And Tools

    INSTALLATION SECTION 3 7834998 INSTRUCTIONS EQUIPMENT AND TOOLS Page 6 of 26 Table 1 Supplied Equipment and Tools General Table Item Description Contained in Kit Part No Reflector Shield Set Radome Feed TF-4-FREQ-19 Feed Hardware Kit 6-15GHz 7613039 M4 x 12lg SHCS, sst, pass M4 Lock Washer, sst, pass Conductive Grease (tube) Feed Hardware Kit 4GHz...
  • Page 7 INSTALLATION SECTION 3 7834998 INSTRUCTIONS EQUIPMENT AND TOOLS Page 7 of 26 Table 1 Supplied Equipment and Tools Item Description Contained in Kit Part No 7679221 M10 x 35lg Hex Hd Screw, sst, pass M10 Lock Washer, sst, pass M10 FlatWasher, sst, pass 7679221 M10 x 50lg Hex Hd Screw, sst, pass M10 Lock washer, sst, pass...
  • Page 8 INSTALLATION SECTION 3 7834998 INSTRUCTIONS EQUIPMENT AND TOOLS Page 8 of 26 6-15GHz only D3/D4 4GHz only 4/6GHz only...
  • Page 9 INSTALLATION SECTION 3 7834998 INSTRUCTIONS EQUIPMENT AND TOOLS Page 9 of 26...

  • Page 10: Tool Requirements

    INSTALLATION SECTION 3 7834998 INSTRUCTIONS EQUIPMENT AND TOOLS Page 10 of 26 Tools TOOL REQUIREMENTS Bolt Diameter in MM Tools Required Ring and Open spanner (A/F) 10mm 17mm 19mm Torque Wrench Sockets (A/F) 10mm 17mm 19mm Allen Key (A/F)

  • Page 11: Section 4 Unpacking

    INSTALLATION SECTION 4 7834998 INSTRUCTIONS UNPACKING Page 11 of 26 Instructions for opening crate: 1. Release wire tabs if present on the outside of the crate 2. Remove the crate's rear panel 3. The reflector can then be hinged backwards from the bottom edge and removed from the crate 4.

  • Page 12: Section 5 Shield Assembly

    INSTALLATION SECTION 5 7834998 INSTRUCTIONS SHIELD ASSEMBLY Page 12 of 26 Shield assembly sequence LEFT-L RIGHT-R BOTTOM-B TOP-T Loosely join ends of shield segments with screws, lock washers and nuts Reflector mounting holes Radome mounting nut Typical overlap arrangement Absorber Drain hole Reflector mounting slot...
  • Page 13 INSTALLATION SECTION 6 7834998 INSTRUCTIONS ASSEMBLY OF REFLECTOR TO SHIELD Page 13 of 26 Fit loosely with lockwasher and nut in 4 Insert shield in to reflector so that mounting opposite places as shown holes align with rim holes in reflector Ensure highest side of shield set is aligned to top of antenna...
  • Page 14 INSTALLATION SECTION 7 7834998 INSTRUCTIONS FEED ATTACHMENT AND ALIGNMENT Page 14 of 26 Vertex Plate Assembly 4/6 GHz only Apply Loctite Nutlock to threads prior to assembly Tighten to 2.5Nm ± 5%...
  • Page 15 INSTALLATION SECTION 7 7834998 INSTRUCTIONS FEED ATTACHMENT AND ALIGNMENT Page 15 of 26 Prior to feed attachment, carefully tilt antenna upright and hold in position. REFER TO SAFETY NOTE ON PAGE 5 For 6-15GHz only Apply grease to surfaces indicated Please ensure flat in feed hub is in a horizontal position...
  • Page 16 INSTALLATION SECTION 7 7834998 INSTRUCTIONS FEED ATTACHMENT AND ALIGNMENT Page 16 of 26 For 4GHz only Apply grease to surfaces indicated Align timing slot in adaptor plate with notch in hub mounting ring casting Finger tighten 6-off flanged screws (fully tightened on final alignment) After assembly, remove excess grease from internal reflector surface...
  • Page 17 INSTALLATION SECTION 8 7834998 INSTRUCTIONS RADOME ATTACHMENT Page 17 of 26 After feed attachment, carefully tilt antenna flat. Unfold radome on to a suitable surface and assemble radome rim tensioners at 4 places. Ensure radome rim tensioners are pressed fully home. (When fully pressed home, tensioners are no longer loose or removable) Pull radome tab to take up any excess...
  • Page 18 INSTALLATION SECTION 9 7834998 INSTRUCTIONS MOUNT ASSEMBLY AND ATTACHMENT Page 18 of 26 Remove braces and discard fixings. Carefully lay antenna on clear, flat ground. Do not apply excesive weight to antenna assembly. 38Nm 5% Assemble bracket Flat washers x 2 Apply grease to areas indicated SEE SAFETY...
  • Page 19 INSTALLATION SECTION 9 7834998 INSTRUCTIONS MOUNT ASSEMBLY AND ATTACHMENT Page 19 of 26 Apply grease to surface indicated SEE SAFETY NOTE PAGE 4 38Nm 5% 38Nm 5% 38Nm 5%...

  • Page 20: Section 10 Mount Adjustment

    INSTALLATION SECTION 10 7834998 INSTRUCTIONS MOUNT ADJUSTMENT Page 20 of 26 38Nm 5% SLING Elevation adjustment nut Loosen, do not remove. NEVER WALK UNDER HOISTED LOADS Loosen, Loosen, do not remove. do not remove. Elevation adjustment Loosen 3 screws (item 1). Rotate bolt head (item 2) to adjust elevation .

  • Page 21: Pan Right

    INSTALLATION SECTION 10 7834998 INSTRUCTIONS Page 21 of 26 MOUNT ADJUSTMENT Loosen screws G2 and G3 Pan Left Pan Right Azimuth adjustment Adjust eyebolt. On completion tighten all hardware to 38Nm ± 5% Adjustment Range ±15° Torque to 38Nm +/-5% Torque to 38Nm +/-5%...
  • Page 22 INSTALLATION SECTION 11 7834998 INSTRUCTIONS Page 22 of 26 STRUT ATTACHMENT Tighten all hardware to 38Nm+/-5% after final alignment Strut to be attached to center hole. Tighten all hardware to 38Nm+/-5% after final alignment...
  • Page 23 INSTALLATION SECTION 11 7834998 INSTRUCTIONS STRUT ATTACHMENT Page 23 of 26 Struts must be attached to a structural member capable of supporting 2704N in line with TIA-222. The maximum allowable relative deflection between the antenna mounting pipe and the strut attachment point must be less than 2mm at the survival wind speed of the antenna.
  • Page 24 INSTALLATION SECTION 11 7834998 INSTRUCTIONS Page 24 of 26 STRUT ATTACHMENT For attachment to circular structural members Torque to 38Nm 5% MIN PIPE 50mm MAX PIPE 115mm Torque to 38Nm 5% For attachment to angle structural members Torque to 38Nm 5% Torque to 38Nm 5% Torque to 38Nm 5%...
  • Page 25 INSTALLATION SECTION 11 7834998 INSTRUCTIONS STRUT ATTACHMENT Page 25 of 26 • Image shown is intended as a guide for strut alignment • Strut must be attached to an appropriate, structural mounting point • Strut angle must not exceed maximum specified •...

  • Page 26: Section 12 General Information

    INSTALLATION SECTION 12 7834998 INSTRUCTIONS GENERAL INFORMATION Page 26 of 26 Antenna Offset Right Antenna Offset Left...
