Quantum™ ädəsē ® RFID Installation Instructions

Testing Lock Functionality

Testing Lock Functionality
Pass a Construction key over the Quantum RFID LPI probe. Be sure that the green light flashes for five Pass a Construction key over the Quantum RFID LPI probe. Be sure that the green light flashes for five
seconds while the exterior lever remains operable. If the green light does not flash, refer to the table seconds while the exterior lever remains operable. If the green light does not flash, refer to the table
below. below.
Lock Communication
Red and green LEDs flash
nine times simultaneously
Yellow LED flashes 12 times
Yellow LED flashes two times
Red and green LEDs flash
alternately nine times
Yellow and red LEDs flash
two times simultaneously
Red LED flashes two times
© SAFLOK™
Electronic Function Description
Time and date not set, use the Quantum RFID LPI probe to reset
Dead bolt is thrown or switch cam is not properly aligned
Keycard not allowed OR keycard cancelled by new keycard
Low battery (contact the SAFLOK service department)
Bad keycard read or corrupted data (may require new
keycard)
Keycard not read (keycard inserted upside-down, wrong end,
wrong key?)
INS_QTMADESERFID
Pg. 7 of 8
2/16/2012
