Quantum™ ädəsē ® RFID Installation Instructions
Quantum
Installation Instructions
All parts needed to install the Quantum™ ädəsē
make sure all parts are accounted for before beginning installation. Do not substitute any of the parts. The
use of substitute parts will result in poor performance of the lock.
Proximity Reader Assembly
(A20910-COLOR)
Outside Lever Trim
(A20970-HAND-COLOR)
All information contained herein, including but not limited to product pricing and other intellectual property, is confidential and All information contained herein, including but not limited to product pricing and other intellectual property, is confidential and
intended for the sole use of the addressee(s) so named. Any misuse of this confidential information contained herein may result in intended for the sole use of the addressee(s) so named. Any misuse of this confidential information contained herein may result in
legal action by Computerized Security Systems dba SAFLOK and its parent company. legal action by Computerized Security Systems dba SAFLOK and its parent company.
© SAFLOK™
ädesē
™
®
RFID lock are included with each unit. Please check to
Screw Pack
(A29050-COLOR)
Gear Box
For the standard
mortise only
(24012-1)
Mortise Lock
(A59810-HAND-G)
Mortise, Std.
OR
(A59850-HAND-G)
Mortise, ADB
OR
(A60000-HAND-G)
Mortise, MT, STD, DAJ
OR
(A59990-HAND-G)
Mortise, MT, ADB, DAJ)
INS_QTMADESERFID
(Odyssey) RFID
®
of the lock.
Scalp Plate
(51190-COLOR)
Pg. 1 of 8
Inside Trim Assembly
(QP12XXX-6-XX)
Strike Plate
(30320-HAND-COLOR)
2/16/2012
