DC Folding Fan FLU-254DHK
Power supply
Power consumption
Voltage
Frequency
Cable length of AC adapter
Dimensions
Net Weight
Remote control battery
● The specifications are subject to change without prior notice.
● This unit is only intended to be sold in Hong Kong and Macau.
● The diagram and illustration in this manual are for reference only. The actual product is subject to
manufacturer specifications.
User Manual
Thank you very much for choosing our
product. Please read the User Manual
carefully in order to use this product correctly.
Please keep the User Manual properly after
reading.
[This product is for indoor use only]
Safety Precautions.........................................1
Name of Parts and Function...........................3
How to Use.....................................................4
Maintenance and Storage.............................10
Troubleshooting............................................13
Specifications
DC 24V, AC adapter (dedicated)
About 13.5W (when using a dedicated AC adapter)
220V
50 Hz
About 1.8m
Width 36.5 × depth 45 × height 46~79cm（when bracket unfolded）
About 2.4kg (excluding the remote control and AC adapter)
Lithium battery (CR2025)
DOSHISHA Co., Ltd.
Contents
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for DOSHISHA FLU-254DHK
Summary of Contents for DOSHISHA FLU-254DHK
-
Page 1: Table Of Contents
DC Folding Fan FLU-254DHK User Manual Thank you very much for choosing our product. Please read the User Manual carefully in order to use this product correctly. Please keep the User Manual properly after reading. [This product is for indoor use only] Contents Safety Precautions.........1... -
Page 2: Safety Precautions
Safety Precautions Please read Safety Precautions carefully in order to ensure proper use Please read and abide by the critical safety information listed in this section carefully Please keep it properly after reading Warning Incorrect operation may cause a risk of death or serious injury Incorrect operation may cause personal injury or property damage Attention (including residence, family properties, livestock and pets) - Page 3 Attention When unplugging the AC adapter, Do not use a battery other than Do not get your hair too close to be sure to hold the AC adaptor specified. the device. instead of the power cord. It may cause liquid leakage. It may cause personal injuries due It may cause electric shock, short to hair being caught.
-
Page 4: Name Of Parts And Function
Name of Parts and Function Operation panel Remote control Display area The current status can be confirmed by the indicator light around the operation button. Air volume display Display the air volume during operation. The stronger the air volume, the more indicators are displayed. -
Page 5: How To Use
How to Use Packing List After purchase, please confirm if the following accessories are complete Main unit·······················································1pcs Coin lithium battery (CR2025)····························1pcs Remote control···············································1pcs User Manual···················································1pcs AC adapter····················································1pcs Warranty Card················································1pcs ※ Do not throw away the packaging materials after assembly, which can be used to store the product after use. Do not turn on the power before the blades and guards are installed. - Page 6 How to Use Use in high position Use in low position Use in sideways position Fully open Fixing strap strained Fixing strap strained Fully open (Lay down the side with Fixing strap strained lateral support) Direction of Fully open the wind 2.
- Page 7 Memory function Start/stop operation When you press the power button on the main unit or the 1. Start operation remote control, operation will start from the last setting mode when the unit was turned off (air volume and swing angle) Simply press the power button on the main unit or remote control to start the operation.
- Page 8 How to Use (cont.) Remote control Operation Panel Display area The current status can be confirmed by the indicator light around the operation button. Air volume display Display the air volume during operation. The stronger the air volume, the more indicators are displayed.
- Page 9 5. Stop operation Setting swing centering on the center of the main unit During operation, simply press the power button Adjusting method of swing center the main unit or the remote control to stop. In the state where there is no swing, press the power button to stop the operation, manually adjust the Auto-off function...
- Page 10 How to Use (cont.) Setting timer About the timer indicator Off timer setting Each time you press the timer button on the main unit or remote control, the timer indicator will switch in When off timer is set, the fan will automatically stop sequence as follows.
-
Page 11: Maintenance And Storage
Maintenance and Storage Before cleaning or maintenance, be sure to unplug the AC adapter from the power socket. It may cause electric shock, fire, or injury. Warning Notice Internal cleaning and maintenance Never use household detergents or diluents, volatile Remove the front guard and the fan blade as described ●... - Page 12 Installation method Insert the fan blade according to the shape of the motor shaft, and then turn the spinner to the left and lock it securely. Install the U-shaped groove of the front guard to the U-shaped groove of the rear guard and rotate it to the right (clockwise).
- Page 13 Folding and minimizing the support frame The unit can be folded (minimized) in a compact state when it is not in use. 1. Stop the operation with the fan blades facing the front, unplug the AC adapter from the power socket, and remove the DC plug from the main unit.
-
Page 14: Troubleshooting
Troubleshooting Warning Only qualified technicians are allowed to disassemble or repair the fan. Check according to the following table when you think it may have “failure”. Problem Cause Solution ● DC plug of AC adapter falls off the DC Insert the DC plug of AC adapter into the DC power connector power connector No power...
