Installation Procedures - Cascade F Series Service Manual

I
NTRODUCTION

Installation Procedures

2.3
1
Attach overhead hoist
3
Mount on truck carriage
ITA Class II – .60-.66 in. (15-17 mm)
ITA Class III – .72-.78 in. (18-20 mm)
ITA Class IV – .72-.78 in. (18-20 mm)
ITA Class II – .32-.36 in. (7-9 mm)
ITA Class III – .39-.43 in. (10-11 mm)
ITA Class IV – .47-.51 in. (12-13 mm)
4
Install lower hooks
115-125 ft.-lbs
(155-170 Nm)
208743 Rev. 1
1000 lb.
450 Kg.
FP0007.eps
Center
Notch
Truck
Carriage
2
Remove lower hooks
Upper
Bearings
GA0035.eps
FP0520.eps
FP0023.eps
FP0025.eps
FP0521.eps
.09 in. FP0010.eps
(2.3 mm)
3
