- Page 1 DM-RMC-100-STR HD Streaming Receiver and Room Controller 100 Supplemental Guide Crestron Electronics, Inc.
- Page 2 HDMI Licensing LLC in the United States and/or other countries. Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others.
-
Page 3: Table Of Contents
User Interface Overview Accessing the User Interface ................... 1 Opening a Web Browser Directly ............... 2 Opening a Web Browser within the Crestron Toolbox Application ....2 Logging In to the DM-RMC-100-STR ............3 Navigating the User Interface .................. 4 Status and Configuration Viewing DM-RMC-100-STR Status Information ............ -
Page 5: Introduction
Guide (Doc. 7651). User Interface Overview The user interface of the DM-RMC-100-STR consists of built-in web pages that allow configuration of stream, on-screen display, HDMI output, network, and device settings. In addition, information about the DM-RMC-100-STR as well as the connected display can be viewed. -
Page 6: Opening A Web Browser Directly
Opening a Web Browser Directly To access the user interface by opening a web browser directly, do the following: 1. Find the IP address or host name of the DM-RMC-100-STR by doing either of the following, respectively: • To find the IP address, press the SETUP button on the device and note the IP address on the connected display. -
Page 7: Logging In To The Dm-Rmc-100-Str
“Changing the User Name and Password" on page 18. 2. Click the button that allows login to the DM-RMC-100-STR. If the browser being used displays the same dialog box as the one shown above, click Log In. -
Page 8: Navigating The User Interface
The navigation bar provides access to the web pages as follows: • Clicking Status accesses the Status page, which provides general information about the DM-RMC-100-STR as well as network-related information. For additional information, refer to “Viewing DM-RMC-100-STR Status Information” on the following page. -
Page 9: Status And Configuration
Viewing DM-RMC-100-STR Status Information General information, such as model name, serial number, and firmware version of the DM-RMC-100-STR, can be viewed. The current network settings, such as host name and IP address, can also be viewed. To view status information, do the following: In the navigation bar, click Status. The Status page opens. -
Page 10: Configuring Stream Settings
Network-related information, which consists of the following: Host Name NOTE: In the sample Status page shown on the previous page, the default host name is DM-RMC-100-STR-00107f36fc84, where 00:10:7f:36:fc:84 is the MAC address of the device. IP Address Subnet Mask Default Gateway... - Page 11 GUIDELINES Initiation Specifies the streaming method used to determine when the DM-RMC-100-STR is to begin streaming. In the Initiation drop-down list, select one of the following: • By Receiver: (Default setting) Specifies a unicast RTSP, HLS (HTTP Live Streaming), or MPEG DASH (Dynamic Adaptive Streaming over HTTP) stream.
- Page 12 MPEG-2 TS. • Independent RTP Streams: (Default setting) Allows the DM-RMC-100-STR to stream the audio and video as separate RTP streams. Each RTP stream uses a different port. Refer to the documentation of the transmitting device to verify that this setting should be used.
- Page 13 1680x1050@60Hz 1280x720@60Hz 1680x1050@60Hz RB 1280x768@60Hz 1920x1080i@25Hz 1280x768@60Hz RB 1920x1080i@30Hz 1280x800@60Hz 1920x1080@24Hz 1280x800@60Hz RB 1920x1080@50Hz 1280x960@60Hz 1920x1080@60Hz 1280x1024@60Hz 1920x1200@60Hz RB The default setting is Auto (Recommended). (Continued on following page) DM-RMC-100-STR: HD Streaming Receiver • 9 Supplemental Guide – DOC. 7846A...
- Page 14 Begin streaming by selecting the Start button ( ). The button starts blinking green every 500 milliseconds while the DM-RMC-100-STR sets up the stream. When the stream starts, the button becomes solid green. In addition, the Status field (read only) indicates that the stream started.
-
Page 15: Configuring On-Screen Display Settings
In the Font Size drop-down list, select one of the following options: • Custom: (Default setting) Allows a custom point size to be set in the Font Size spin box • Small: Sets a fixed point size of 22 DM-RMC-100-STR: HD Streaming Receiver • 11 Supplemental Guide – DOC. 7846A... -
Page 16: Configuring Image Overlay Settings
• Drop shadow • Color • Scrolling Configuring Image Overlay Settings The following image file formats can be uploaded to the DM-RMC-100-STR and then be overlaid on the display device: • PNG with alpha channel • JPEG • To configure image overlay settings, do the following: 1. - Page 17 If the image path type is set to Local, click the Browse… button, navigate to the desired image file, and then click Open. The image file is uploaded from the local device to the DM-RMC-100-STR. The filename appears in the Browse… box.
-
Page 18: Configuring Hdmi Output Settings
4. In the Underscan drop-down list, select the desired underscan percentage. The underscan percentage reduces the size of the image, resulting in black bars around the image. Available values are Custom, 0.0% (default setting), 2.5%, 5.0%, and 7.5%. 14 • DM-RMC-100-STR: HD Streaming Receiver Supplemental Guide – DOC. 7846A... - Page 19 Manufacturer: Specifies the name of the manufacturer of the connected display • Name: Specifies the model name of the connected display • Serial Number: Specifies the serial number of the connected display DM-RMC-100-STR: HD Streaming Receiver • 15 Supplemental Guide – DOC. 7846A...
-
Page 20: Configuring Network Settings
Domain Name Specifies a domain name. DHCP Specifies whether the IP address of the DM-RMC-100-STR is to be assigned by a DHCP (Dynamic Host Configuration Protocol) server. To set the IP address, click either of the following radio buttons: • Obtain an IP address automatically: (Default setting) Allows... -
Page 21: Configuring Device Settings
3. Do either of the following: • To save the current entries, click the Save button. The DM-RMC-100-STR automatically reboots. • To revert to the previous settings without saving the current entries, click the Revert button. Configuring Device Settings Configuration and management of device settings consist of the following: •... -
Page 22: Changing The User Name And Password
NOTE: When the LEDs are disabled, all LEDs—including the power and Ethernet LEDs— turn off. The DM-RMC-100-STR appears as though it is not powered on and functioning; however, the device remains powered on and continues to function. 18 • DM-RMC-100-STR: HD Streaming Receiver... -
Page 23: Upgrading Firmware
By default, the LEDs are enabled. • To disable the display of the LEDs, click the Disabled radio button. Although the LEDs become disabled, the DM-RMC-100-STR continues to function. Upgrading Firmware To upgrade firmware of the DM-RMC-100-STR, do the following: 1. -
Page 24: Restoring Factory Default Settings
3. Click OK to restore factory default settings and to reboot the device. Rebooting the DM-RMC-100-STR To reboot the DM-RMC-100-STR, do the following: 1. In the navigation bar, click Device. The Device page, which includes a Device Management section, opens. - Page 25 This page is intentionally left blank. DM-RMC-100-STR: HD Streaming Receiver • 21 Supplemental Guide – DOC. 7846A...
- Page 26 Crestron Electronics, Inc. Supplemental Guide – DOC. 7846A 15 Volvo Drive Rockleigh, NJ 07647 (2045394) Tel: 888.CRESTRON 12.15 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
