Global Parameters Data Dump
Value Description
System Exclusive (SysEx)
1111 0000
DSI ID
0000 0001
Pro 3 ID
0011 0001
Main Parameter Data
0000 1111
50 nibbles (LS then MS) for 25 Global parameters
0vvv vvvv
End of Exclusive (EOX)
1111 0111
The Global Parameters Data Dump is not recognized when received. It is only
transmitted when requested. NRPN messages are used to change Globals.

Packed Data Format

Data is packed in 8 byte "packets", with the MS bit stripped from 7 param-
eter bytes, and packed into an eighth byte, which is sent at the start of the 8
byte packet.
Example:
Input Data
1 A7 A6 A5 A4 A3 A2 A1 A0
2 B7 B6 B5 B4 B3 B2 B1 B0
3 C7 C6 C5 C4 C3 C2 C1 C0
4 D7 D6 D5 D4 D3 D2 D1 D0
5 E7 E6 E5 E4 E3 E2 E1 E0
6 F7 F6 F5 F4 F3 F2 F1 F0
7 G7 G6 G5 G4 G3 G2 G1 G0
150 Appendix F: MIDI Implementation
Packed MIDI data
1 00 G7 F7 E7 D7 C7 B7 A7
2 00 A6 A5 A4 A3 A2 A1 A0
3 00 B6 B5 B4 B3 B2 B1 B0
4 00 C6 C5 C4 C3 C2 C1 C0
5 00 D6 D5 D4 D3 D2 D1 D0
6 00 E6 E5 E4 E3 E2 E1 E0
7 00 F6 F5 F4 F3 F2 F1 F0
8 00 G6 G5 G4 G3 G2 G1 G0
