Page 1
MICROWAVE OVEN INSTRUCTION MANUAL Model: FMO16AHTBSD Read these instructions carefully before using your microwave oven, and to maintain its upkeep. If you follow the instructions, your oven will provide you with many years of good service. KEEP THESE INSTRUCTIONS IN A SAFE PLACE (rev.
(3) DOOR SEALS AND SEALING SURFACES (Do not use if the door seal or sealing surfaces are damaged.) (d) The oven should not be adjusted or repaired by anyone except properly qualified service personnel. SPECIFICATIONS Model: FMO16AHTBSD Rated Voltage: 120V~60Hz Rated Input Power (Microwave):...
Page 5
IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances basic safety precautions should be followed, including the following: WARNING - To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy: 1� Read all instructions before using the appliance. 2�...
To reduce the risk of injury to persons: 1� Do not overheat the liquid. 2� Stir the liquid both before and halfway through heating it. 3� Do not use straight-sided containers with narrow necks. 4� After heating, allow the container to stand in the microwave oven for a short time before removing the container.
RADIO INTERFERENCE 1� Operation of the microwave oven may cause interference to your radio, TV or similar equipment. 2� When there is interference, it may be reduced or eliminated by taking the following measures: 3� Clean door and sealing surface of the oven. a�...
UTENSILS CAUTION – Personal Injury Hazard Tightly-closed utensils could explode. Closed containers should be opened and plastic pouches should be pierced before cooking. See the instructions on “Materials you can use in microwave oven or to be avoided in microwave oven.” There may be certain non-metallic utensils that are not safe to use for microwaving.
Page 9
MATERIALS YOU CAN USE IN MICROWAVE OVEN Utensils Remarks Browning dish Follow manufacturer* instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the turn- table to break. Dinnerware Microwave-safe only. Follow manufacturer’s instructions. Do not use cracked or chipped dishes.
SETTING UP OUR OVEN Names of Oven Parts and Accessories Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories. Glass tray (turntable) Turntable ring assembly Instruction manual Sensor Frozen Frozen Reheat Pizza Entrée...
Page 11
Countertop Installation Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged. Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron. 12 inch(30cm) 3.0 inch(7.5cm) OPEN...
OPERATION 1. Power Level Ten power levels are available. Number key Level Power 100% Display PL10 2. Clock Setting When the microwave oven is plugged into a outlet, the oven will display " 0:00 " 1) Press " CLOCK ", the screen will display 00:00 . The hour figure will flas h; ":" and other "0"...
Page 14
4. Microwave cook 1) Press " COOK TIME" once, the screen will display "00:00". 2) Press number keys to input the cooking time; the maximum cooking time is 99 minutes and 99 seconds. 3) Press " POWER LEVEL " once, the screen will display "PL10". The default power is 100% power.
Page 15
Sensor Cook 1) In waiting s tate, put the food in the oven pres s the menu key in the s ens or cook 2) Press " START/+30SEC " to start sensor cook function and no need to set time. 3) When the steaming is emanated, the surplus time will display.
Page 16
Note:1) Food to be avoided in sensor reheating. a.Bread and other dry food, such as biscuit,cake. b.For raw or uncooked foods. c.Beverage and frozen food. 2)The oven cannot cook automatically when the temperature of the oven cavity is high. 3)The reheat food can be covered with the lid. But the lid must has venthole in order to emanate the steam.
Page 17
Sensor Cook Chart Food Weight/ Menu button Food Code Portion Sensor Reheat Sensor Reheat SC-1 8.0~32.0 oz Frozen Pizza Frozen Pizza SC-2 6.0~12.0 oz SC-3 8.0~32.0 oz Frozen Entr e é Frozen Entr e é 1~4 potatoes Potato Potato SC-4 10.0 oz each 8 .0 oz ~...
Page 18
POPCORN 1) Press " POPCORN " repeatedly until the weight you needed appears in the display, "Oz" light. For example, press " POPCORN " once, "1.75" displays. START/+30SEC. " to cook, "Oz" disappears. 2) Press " Display Weight Times( Press " POPCORN ") 1.75 Oz 1.75 O n c e...
Page 19
10. MEMORY FUNCTION 1) Press " MEMORY " to choose memory 1-3 procedure. 1,2,3 will display. 2) If the procedure has been set, press " START/+30SEC. " to use it. If not, continue to set the procedure. Only one or two microwave stages can be set. 3) After finishing the setting, press "...
Page 20
12. INQUIRING FUNCTION If the clock has been set, i n cooking state, press " CLOCK ", the clock will displays for three s econds . After that, the oven will turn back to the clock state. 2) In the microwave cooking state, press " POWER LEVEL " to inquire microwave power level the current microwave power will be displayed.
MAINTENANCE Troubleshooting Check your problem by using the chart below and try the solutions for each problem. If the microwave oven still does not work properly, contact the nearest authorized service center Trouble Possible Cause Possible Remedy a. Electrical cord for oven is not plugged in. a.
Page 22
ONE YEAR LIMITED WARRANTY This warranty applies to products purchased and used in the U.S. and Canada. This is the only expressed warranty for this product and is in lieu of any other warranty or condition. This product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of original purchase.
