DUCTLESS KIT (#DUCTCLAS) INSTALLATION INSTRUCTIONS
INSTRUCTIONS D'INSTALLATION DE DUCTLESS (#DUCTCLAS)
FOR USE WITH THE FOLLOWING PRODUCTS:
POUR L'USAGE AVEC LES PRODUITS SUIVANTS:
This kit consists of:
A) 2 CHARCOAL FILTERS
B) DUCTLESS DIVERTER
CLASSICA 30 (CLAS30SS)
CLASSICA 36 (CLAS36SS)
Ce kit se compose :
A) 2 FILTRE de CHARBON DE BOIS
B) AIGUILLAGE SANS CANAL
B
A
Version 02/11- Page 1
