Infinite Peripherals INFINEA X MINI Quick Start Manual page 2

CHARGING
1. Attach the charging cup to the bottom of
the Infinea X Mini.
2. Plug the USB end into an AC wall adapter
( the AC adapter must support at least 2.1
amps ).
LED BATTERY STATUS
100% - 75% Solid green
74% - 50% Blink green
49% - 25% Blink orange
24% - 10% Blink red
9% - 1% One LED blinks red/emergency
low battery
SDK
Integrating the Infinea X Mini into your iOS
application requires the use of the Infinite
Peripherals mobile device Software Developer's
Kit (SDK). For the latest Infinite Peripherals
mobile device SDK, visit our developer portal
ipcmobile.com/developer.
PRODUCT RETURNS
Use the link provided to create an account
and gain access to our Knowledge Base and
online support services. Through our online
support center, you'll be able to download
files, open a Support Ticket, manage your
RMAs, view your account Profile and
subscribe to Alerts.
To request a RMA:
1. Create a user account in the RMA
Support Portal at https://ipcmobile.com/
support/rma/
2. Login to your user account, and then
click Create RMA Request.
3. Read the instructions provided and
complete the online request form.
4. Note the assigned RMA number and
write it clearly on your shipping carton.
5. Ship your equipment back to us at the
address provided.
QSG-10013 Rev. C
ACCESSORIES
Please visit our Accessories page at ipcmobile.
com, or contact your Infinite Peripherals sales
representative for more information about
available chargers and battery packs for the
Infinea X Mini.
COMPATIBILITY
Made for
:
• iPad mini™ 4 mobile digital device
• iPad mini™ 3 mobile digital device
• iPad mini™ 2 mobile digital device
SYNCING
The Infinea X Mini portable barcode scanner
is designed specifically for use with iPad mini
by allowing the iPad mini to sync with iTunes®
through the Infinea X Mini while connected.
1. Ensure the Pass Through Sync option is
enabled in the SDK.
2. Connect the Infinea X Mini to a computer
using the Charging Cup.
WARRANTY
Infinite Peripherals does not warrant, and is not
responsible for, any damage to the Infinea X Mini
("Product") or the assembled iOS product as
a result of liquid or solid particle intrusion into
the Product or damaged caused by dropping
the Product with the assembled iOS product.
If a material or workmanship defect arises with
regard to any Product, and a valid claim is
received within the Warranty Period, Infininte
Peripherals (at its discretion) will (1) repair the
Product using new or refurbished parts or (2)
replace the Product with a new or refurbished
Product. For purposes of this limited warranty,
"refurbished" means a product or part that
has been substantially returned to its original
specifications. In the event of a defect, these are
your exclusive remedies.
Part Numbers: IX-I2DBTR-MR-XX, IX-I2DBTR-M4-XXX
TROUBLESHOOTING
iOS device will not sync to iTunes
• Infinea X Mini is not configured for sync.
Swipe gestures not detected by iOS device
• Top cover is not properly installed.
Audio playback not heard from front
speakers
• iOS device is not connected to audio jack.
• Infinea X Mini front speaker cable is damaged
or disconnected.
Audio playback not heard from rear speakers
• iOS device is not connected to audio jack.
• Rear speaker not powered.
iOS device does not charge
• AC adapter may not meet charging
requirements.
• Pass Through Sync is enabled.
