- Page 1 SB SOUNDBARS SB MULTI-USE SPEAKERS QUICK START INSTALLATION GUIDE Rev A 191104 Theory sb QUICK START Rev A 191104...
- Page 2 LIMITED WARRANTY Disclaimer : THEORY AUDIO DESIGN, LLC is not liable for any damage to loudspeakers or any other equipment that is caused by negligence or improper use or installation of this product, including damage caused by connecting Theory loudspeakers and subwoofers to third party ampli- fiers.
- Page 3 16. Mount Z-CLIP hardware to studs whenever possible. Use drywall anchors only when studs are not available. Connect to Theory or Pro Audio Technology Amplified Loudspeaker Controllers ONLY. Do not connect to third-party amplifiers. Doing so will void the product warranty and potentially damage the loudspeaker.
- Page 4 QUICK START GUIDE - SB MODELS SOUNDBAR MODELS MOUNT TO WALL ONLY - GET HELP Your Theory SOUNDBAR is heavy and must be mounted securely to a wall, it cannot be mounted to your TV or TV mount. You will need at least three people to safely mount your SOUNDBAR.
- Page 5 FIGURE 5B. Duplicate Z-CLIP spacing on rear position. from the center mark to each Z-CLIP of your Theory SOUNDBAR keeping in mind the spacing will be reversed. 6 - ROUTE SPEAKER WIRE If you haven’t already done so, run 3 speaker wires for LEFT, CENTER and RIGHT speakers to the SOUNDBAR center location.
- Page 6 © 2019 THEORY AUDIO DESIGN, LLC. All rights reserved. Theory Audio Design routinely engages in programs to improve, modify and revise its products without notice or obligation. As such, your product may differ slightly from what is shown in this guide.
