Sensor Offset Adjust - GRAPHTEC FC8000 Series Quick Start Manual

V ADV -SCREEN 1/3
3 LENGTH UNIT>INCH
^
INTERFACE SCREEN 1/3
1COMMAND
3AUTO
- IF APPLICABLE FOR ETHERNET OPTION -DOWN ARROW TO SCREEN 2/3
LAN
IP
GATEWAY
4 MEDIA -SCREEN 1/2
1PREFEED -3.3'
2AUTO PREFEED
1ON
2PAGE LENGTH 3.3FT
3PAGE LENGTH-1968.5"
4INITIAL FEED
1OFF

SENSOR OFFSET ADJUST

Per Graphtec we need to begin using "Sensor Offset Adjust" rather than "Axis Origin Offset." Both methods
result in shifting the cut lines but, the Sensor Offset Adjust will NOT move the ORIGIN point.
REMEMBER: Increase the X and Y values shift the cut lines to the upper left (if you are standing in front of the
cutter.) Y = (right to left, positive values shift left) X = (down to up, positive values shift cut lines up)
The Sensor Offset Adjust is done by doing the following:
1.) Ensure the customer has "Ready" displayed on the screen.
2.) Hit the "ENTER" key.
3.) Hit number "2" for the ARMS menu.
4.) Arrow down to "Sensor Offset Adjust"
5.) Hit "1" for "Sensor Offset Adjust"
6.) Hit number "3=X" or "4=Y"
7.) Arrow up or down to increase or decrease the values.
8.) Once the values are set hit the "left arrow" or "Previous" then hit enter to confirm.
