- Page 1 AIR WALKER IMPORTANT: Read all instructions carefully before using this product. Retain this owner’s manual for future reference. The specifications of this product may vary from this photo and, subject to change without notice. Item #3409...
- Page 2 3409.1-102415...
-
Page 3: Table Of Contents
TABLE OF CONTENTS SERVICE ---------------------------------------------------------------------- LABEL PLACEMENT ------------------------------------------------------- IMPORTANT SAFETY INSTRUCTIONS ------------------------------ OVERVEW DRAWING ----------------------------------------------------- PART LIST -------------------------------------------------------------------- ASSEMBLY ------------------------------------------------------------------- STORAGE--------------------------------------------------------------------- MOVING THE BIKE--------------------------------------------------------- COMPUTER--------------------------------------------------------------------- 11 WARM UP----------------------------------------------------------------------- WARRANTY--------------------------------------------------------------------- 13 FAX -------------------------------------------------------------------------------... -
Page 4: Service
SERVICE IMPORTANT: FOR NORTH AMERICA ONLY For damage or defective product, questions, replacement parts or any other service support, please contact our customer service department (8:00 AM - 5:00 PM Pacific Standard Time, Daily) by below methods: For Best Service Email: Service@paradigmhw.com Response Time: 1-2 Business Days Website:... -
Page 5: Label Placement
LABEL PLACEMENT... -
Page 6: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Basic precautions should always be followed, including the following safety instructions when using this equipment. Read all instructions before using this equipment. 1. Before exercising and to avoid injuring your muscles, it is highly recommended that you perform warm-up exercises for each muscle group. Please refer to Warm Up section of the Owner’s Manual. -
Page 7: Overvew Drawing
OVERVIEW DRAWING... -
Page 8: Part List
PART LIST Description Qty No. Description Round Cap φ31*26 28 Hand Pulse Handlebar 29 Hand Pulse Sensor Foam φ23*3*480 30 Bushing φ15*30 Round Cap φ69*φ50 31 Sensor Phillips Pan Head Screw Hex Bolt M10*25*S17 ST4.8*10*φ8 33 Round Magnet φ6*5 Spring Washer d10 Hex Socket Head Screw Washer d10.2*φ50*3 M8*38*15*S6... -
Page 9: Assembly
ASSEMBLY Step 1 Unfold the Pedals A. Unscrew Round Knob (49) and Washer (46) from Rear Stabilizer (47) B. Place Rear Stabilizer (47) flat on the ground, and tighten Round Knob (49) with Washer (46) to the side of Main Frame (38) C. - Page 10 ASSEMBLY Step 2 Handlebars Installation Unscrew Hex Socket Head Screws (15) from Handlebar Bracket (11R). Insert Handlebar (2) into Handlebar Bracket (11R) and align the screw holes. Tighten Hex Socket Head Screws (15) to secure Handlebar (2) and repeat for left Handlebar (2).
-
Page 11: Storage
STORAGE For your convenience, the walker can be folded for storage. A. Fold Pedals (41R & 41L) B. Remove Round Knob (49) and Washer (46) from the side of Main Frame (38). C. Fold and secure Rear Stabilizer (47) against Main Frame (38) with Round Knob (49) and Washer (46). -
Page 12: Moving The Bike
MOVING THE WALKER By holding down Handlebars (53), you may use Round Wheels (35) to move the air walker. Please beware the swing leg will be lower toward the body... -
Page 13: Computer
COMPUTER SPECIFICATIONS: SCAN------------------ Changeable display each function for every 6 seconds, it will cycle showing. TIME------------------- 0:00~99:59 COUNT---------------- 0~9999 CALORIES----------- 0~9999 PULSE---------------- 30~240 BPM OPERATION: Press MODE until SCAN appears on the screen; the computer SCAN automatically scan through each function value every six seconds on the display. -
Page 14: Warm Up
WARM UP Quadriceps Stretch With one hand against a wall for balance, reach behind you and pull your right foot up. Bring your heel as close to your buttocks as possible. Hold for 15 counts and repeat with left foot up. Inner Thigh Stretch Sit with the soles of your feet together with your knees pointing outward. -
Page 15: Warranty
WARRANTY MANUFACTURER’S LIMITED WARRANTY Paradigm Health & Wellness warrants to the original purchaser that this product is free from defects in material and workmanship when used for the purpose intended, under the conditions that it has been installed and operated in accordance with Paradigm’s Owner’s Manual. Paradigm’s obligation under this warranty applies to the following: COMPONENT LENGTH OF WARRANTY... -
Page 16: Fax
FAX FORM Paradigm Health & Wellness, Inc. EMAIL THIS FORM WITH YOUR RECIEPT OF PURCHASE TO Service@paradigmhw.com NAME: _______________________________________________________ ADDRESS: ____________________________________________________ CITY ______________ STATE ______________ ZIP ___________________ TELEPHONE: (Day) ____________________________________________ (Night) ____________________________________________ SERIAL#: _____________________________________________________ MODEL#: _____________________________________________________ PURCHASE DATE: _____________________________________________ PLACE OF PURCHASE: _________________________________________ PART # DESCRIPTION “YOUR ORDER WILL BE PROCESSED WITHIN 3 BUSINESS DAYS”...
