High Performance Self-Priming Engine Pump
PERATI N MANUAL
Thank you for choosing Koshin Hidels Pump.
This manual is prepared for your safety when
operating pump. Please read carefully and
comprehend fully before use.
(Wrong usage could cause injury or death.)
Please keep this manual handy for future
reference.
12 Kami-Hachinotsubo Kotari, Nagaokakyo City, Kyoto 617-8511 JAPAN
TEL.+81-75-954-6111 FAX.+81-75-954-6119
Common points for all series
http://www.koshinpump.com
05-09 012047401tx
Advertisement
Related Manuals for Koshin HIDELS
Summary of Contents for Koshin HIDELS
- Page 1 High Performance Self-Priming Engine Pump PERATI N MANUAL Common points for all series Thank you for choosing Koshin Hidels Pump. This manual is prepared for your safety when operating pump. Please read carefully and comprehend fully before use. (Wrong usage could cause injury or death.) Please keep this manual handy for future reference.
- Page 2 CAUTION 1. Application PRIMING PLUG As this pump is design for agriculture use, do not apply with muddy water. Trouble if you don't observe. Could damage mechanical seal. 2. Priming As this pump is self-priming type, fill water fully into priming port before running. Trouble if you don't observe.
-
Page 3: Safety Precautions
Harmful substances are in exhaust gas. There is danger of gas poisoning. In case of operating Hidels Pump in a well or in a hollow, the person operating the pump must not enter the small space as there is danger of gas poisoning. -
Page 4: Before Use
CAUTION Do not touch muffler or any part of the engine. It could cause burn. Use this pump for clean water or agriculture water. Not Suitable: drinking water, mud water, seawater, kerosene, light oil, heavy oil, gasoline, chemical, acid, alkaline etc. Use correct type of suction hose. - Page 5 4-stroke engine 4-stroke engine needs "engine oil" There is no engine oil in the engine. Before starting engine, engine oil must be filled. If you start engine without engine oil, engine will burn out and it is difficult to repair. (Warranty does not cover such claim.) Please use "Non-Lead Gasoline for Automobile"...
- Page 6 Fill pump with water before use Priming port As pump is self-priming type, fill water fully from priming port into pump before running. Insufficient water can cause damage to pump. Running without filling water can damage CAUTION mechanical seal. HOW TO USE Ensure pump is fully filled up with water.
-
Page 7: Troubleshooting Guide
TROUBLESHOOTING GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Replace to new fuel. If there is no Old fuel improvement, repair engine. Cannot pull Rusting inside engine Refer to Engine Operation Manual. or hard to pull (Repair) Burn out of engine recoil starter Stick impeller Dismantle &... - Page 8 Illustration is SEH-80X Pump casing Impeller Remove obstacle in impeller. (Please don't remove impeller) Volute casing Check suction pipe. In case of no suction or small delivery, the cause is usually due to air leakage at Recoil suction side. In such case : Whether suction or not Remove suction hose Start engine with water inside the pump.
