Leave this manual with party responsible for use
and operation.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
CAUTION! Do not install damaged components.
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during instal-
lation. Sheet metal edges are sharp.
WARNING! Choking Hazard! Keep media out of reach
of children.
WARNING! Risk of Injury! This kit must be installed by
a qualified service technician.
TOOLS
Screw gun equipped with 1/4 in. socket or
1/4 in. wrench
3/8 in. wrench
Instructions for optional glass kit, stone kit or log set if
applicable.
Majestic • CKRUBY30, CKRUBY35 Contemporary Kit Instructions • 2542-939 Rev. B • 2/19
CKRUBY30, CKRUBY35
Models: RUBY30IN, RUBY30IL, RUBY35IN, RUBY35IL
Installation Instructions
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
Note: If an optional LINER kit will be used with the CK-
RUBY30/35, the LINER kit instructions will be needed
during installation of the CKRUBY30/35 kit.
Note: The CKRUBY30/35 is not compatible with fiber
refractory.
BTU Specifications
Models
(U.S. or Canada)
CKRUBY30
(0-2000 FT)
(NG)
CKRUBY30
(0-2000 FT)
(Propane)
CKRUBY35
(0-2000 FT)
(NG)
CKRUBY35
(0-2000 FT)
(Propane)
Preparation
CAUTION! Risk of Burns! The fireplace should be
turned off and cooled before contemporary kit is installed.
• Shut off gas supply and disconnect electrical power.
• Remove decorative front, glass assembly, glass seal
plate, lava rock, embers, logs and refractory, if previ-
ously installed.
Maximum
Minimum
Orifice
Input
Input
Size
BTU/h
BTU/h
(DMS)
28,000
19,600
38
.058
23,000
16,100
in.
30,000
21,000
37
1.55
28,000
19,600
mm
Shutter
Setting
1/2 in.
Full
Open
3/8 in.
Full
Open
1
