- Page 1 CIB 3102 4 Line (400) Module and 8 Line (800) Module CIB 3102 Comcode 105-412-407 Issue 3...
- Page 2 CIB 3102 4 Line (400) Module and 8 Line (800) Module These modules (Figure 1) allow you to connect outside lines to your MERLIN® II Communications System. The 4 Line (400) Module has four outside line jacks and one power failure transfer jack. This module is also equipped with Touch-Tone®...
- Page 3 Inserting and Removing Modules Before inserting or removing modules, be sure to WARNING: turn Off the power switch on the Power Module(s). If your system has an expansion carrier, turn Off the power switch on the basic carrier’s Power Module first, then turn Off the power switch on the expansion carrier’s Power Module.
- Page 4 Remove the cardboard protector from the connector at the back of the module. Make sure that the power switch is Off on the Power Module(s). Fol- low the procedure below for turning the power off at the Power Module(s): If your system has an expansion carrier, first turn Off the power switch on the basic carrier’s Power Module.
- Page 5 INSERTING MODULES REMOVING MODULES 1 Lower the module hook onto the carrier’s rod. 2 Lift the module free of the carrier. Module Carrier’s rod Carrier 2 Gently swing the module toward the carrier, 1 Press up on the release tab then Push the module into the carrier until at the bottom of the module and pull the module away from the carrier.
- Page 6 Replace the front and top covers. REMOVING MODULES Remove modules by following the instructions in Figure 3B and Steps 1, 3, 7, and 8 above. Labeling Jacks on Modules After installing modules, affix a jack label to the right of each jack using the numbering strips (provided with each module) (Figure 4).
